3-9 Parts Location 5OM-1751 1305-002 CPU2 LAN UP DN T DI-1CH DI-2CH SELIAL1 SELIAL2 USB1 USB2 USB3 USB4 X8500 X8501 X8502 X85UP X85DN X85T X8203 X8204 X8109 X8104 X8202 X8201 X8102 U85 U82 U81 Symbol Name Remarks U81 Con…
3-8
Parts Location
5OM-1751
1305-002
CPU1
COM1
COM2
LAN1
LAN2
USB2 USB10
VGA
CAM
I/O
COGNEX
DVI
USB3 USB11
X9201
X9202
X9108
X9107
X9106
X9105
X9109
X9104
X9103
X9102
U92
U91
Symbol Name Remarks
U91 Operation and Recognition CPU
U92 Frame Grabber 1
3-9
Parts Location
5OM-1751
1305-002
CPU2
LAN
UP
DN
T
DI-1CH
DI-2CH
SELIAL1 SELIAL2
USB1
USB2
USB3
USB4
X8500
X8501
X8502
X85UP
X85DN
X85T
X8203
X8204
X8109
X8104
X8202
X8201
X8102
U85 U82 U81
Symbol Name Remarks
U81 Control CPU
U82 Motion Control
U85 AE-LINK/HSIO Host PCB Model UC16
3-10
Parts Location
5OM-1751
1305-002
Head Section Motor Amplier Unit
A31B
A31F
Symbol Name Remarks
A31F Head #2 Servo Motor Amplier
A31B Head #1 Servo Motor Amplier
