Safety Precautions Safe-13 1OM-1751 Alert Indications described as " CAUTION " (continued) Alert Description Related Items Residual voltages may remain behind for a few minutes in the internal devices of the ma…
Safety Precautions
Safe-12
1OM-1751
Alert Indications described as "
CAUTION
" (continued)
Alert Description Related Items
Do not put your hand in the moving area while the feeder base is
moving up or down.
While the LED of the Feeder Ready switches are being ickering, it
indicates that the corresponding feeder base is moving up and down.
"2.2.5" in
"Chapter 1 (Vol. 1)"
When you need to bend down to perform work, you may hit your
head on the tape feeder worktable and get injured.
"2.2.6.1" in
"Chapter 3 (Vol. 1)"
When the tape feeder connecting cable is connected to the tape
feeder, unless the tape feeder is held securely, the tape feeder
holding guide may come o and drop from the tape feeder unit.
Connect the cable with the tape feeder held securely.
"2.2.6.1" in
"Chapter 3 (Vol. 1)"
There are some heavy feeder models. When such feeders are
removed with one hand, the weight of the feeder removed from
the guide cannot be supported by one hand and the feeder might
drop. Remove the feeder using both hands to support it.
"2.2.6.2" in
"Chapter 3 (Vol. 1)"
The padlock key should be kept in such a way that nobody except the
personnel in charge of maintenance can supervise it.
"4.3" in
"Chapter 2 (Vol. 1)"
The load power to the motors, etc., is turned OFF but the setup
operation must be performed carefully when you put your hand
inside the machine. Avoid hand and nger injuries.
"2.3.5" in
"Chapter 3 (Vol. 1)"
"4.1" and "4.2.1" in
"Chapter 6 (Vol. 2)"
Even when the power breaker is set to "OFF", the primary line is
powered, making it possible to cause an electric shock.
Be sure to completely stop the power supply to the machine before
maintenance work.
"1.1" in
"Chapter 1 (Vol. 4)"
1305-002
4. Alert Indications in Instruction Manual
Safety Precautions
Safe-13
1OM-1751
Alert Indications described as "
CAUTION
" (continued)
Alert Description Related Items
Residual voltages may remain behind for a few minutes in the
internal devices of the machine after power interception.
Before performing maintenance work, wait until the charge lamps of
the DC power supply and the servo amplier go "OFF" in 10 minutes
or more after the power breaker is set to "OFF".
"1.1" in
"Chapter 1 (Vol. 4)"
After making sure that the air supply has been stopped and the
cutter blades are closed, start maintenance.
During maintenance, do not touch the cutter blade.
"4.6.2" in
"Chapter 1 (Vol. 4)"
1305-002
4. Alert Indications in Instruction Manual
Safety Precautions
Safe-14
1OM-1751
1303-001
5. Alert Labels
5. Alert Labels
The alert labels (described below) are used for this machine.
Please read the instructions on each label carefully and check the contents, observing the
actual object.
Be sure to follow the instructions for safety purposes.
These labels should be kept clean and easily legible at a far safe distance.
When a label has deteriorated and become illegible, contact the marketing department or
sales agency of Yamaha Motor Co., Ltd. for the replacement with a new one.
