Safety Precautions Safe-19 1OM-1751 1305-002 5. Alert Labels 3 4 4 4 4 3 4 4 4 4 Front View of Machine Front View of Machine (9) (9) (16) (4) (6) (18) Do not put any object on this section. T his might damage t he machin…

100%1 / 190
Safety Precautions
Safe-18
1OM-1751
1305-002
5. Alert Labels
4
4 44
8
8
5
5
CAUTION
Your hand might be caught in the moving section. Do not
put your hand into the cover opening during the machine
operation.
Pay attention to the moving
mechanisms!
10-0249-
Right View of Machine
(10) (19)
CAUTION
Your hand might be caught in the moving section. Do not
put your hand into the cover opening during the machine
operation.
Pay attention to the moving
mechanisms!
F1X4
4
4 44
8
5
5
CAUTION
Your hand might be caught in the moving section. Do not
put your hand into the cover opening during the machine
operation.
Pay attention to the moving
mechanisms!
10-0249-
Left View of Machine
(10) (19)
CAUTION
Your hand might be caught in the moving section. Do not
put your hand into the cover opening during the machine
operation.
Pay attention to the moving
mechanisms!
F1X5
Note
When the opening size (PCB input or output opening) is to be appropriately set for
the product PCB size, consult with the Sales and Marketing Dept., or sales agent of
Yamaha Motor Co., Ltd. Corporation.
Safety Precautions
Safe-19
1OM-1751
1305-002
5. Alert Labels
3
4
4 4
4
3
4
4 4
4
Front View of Machine
Front View of Machine
(9) (9)
(16)
(4)
(6)
(18)
Do not put any object
on this section.
This might damage the machine.
Do not put any object
on this section.
This might damage the machine.
Do not put any object
on this section.
This might damage the machine.
10-0326A
Do not put any object
on this section.
This might damage the machine.
10-0326A
The machine will be break down.
Trained Personnel Only!
10-0252-
The machine will be break down.
Trained Personnel Only!
Keep Linear Guide Grooves
Clear of Any Object!
An object in the groove may be trapped in the
moving part, causing the machine to be damaged.
10-0335-
Keep Linear Guide Grooves
Clear of Any Object!
An object in the groove may be trapped in the
moving part, causing the machine to be damaged.
F1X6
Safety Precautions
Safe-20
1OM-1751
1305-002
5. Alert Labels
Rear View of Machine
Rear View of Machine
(16)
(4)
10-0252-
The machine will be break down.
Trained Personnel Only!
The machine will be break down.
Trained Personnel Only!
F1X7
