10 Service Manual SIPLACE X-Series S (from Hxxxx) 01/2021 Contents:
9Service Manual SIPLACE X-Series S (from Hxxxx) 01/2021
Contents:
9.6.3 Replacing the back section of the cylinder.. 360
9.6.4 Replacing the linear guide.. 361
9.6.5 Replacing the control board.. 362
9.6.5.1 Control board SPS.. 363
9.6.6 Replacing the swivel head.. 364
9.6.7 Replacing the pneumatic cylinder.. 365
9.6.8 Replacing the coil hose.. 366
9.6.9 Replacing the coiled cable.. 367
9.6.10 Replacing the Round Cable.. 369
9.6.11 Replacing the tension spring.. 370
9.6.12 Replacing the top sensor.. 371
9.6.13 Replacing the bottom sensor.. 372
9.6.14 Replacing the one-way restrictor.. 373
9.6.15 Replacing the solenoid valve.. 374
9.6.16 Replacing the solenoid valve cable.. 375
9.6.17 Replacing the press roller.. 376
9.6.18 Replacing the Magazine Recognition Board.. 377
9.6.18.1 Magazine recognition board.. 378
10 Miscellaneous.. 379
10.1 eSW Download (SW 70x).. 379
10 Service Manual SIPLACE X-Series S (from Hxxxx) 01/2021
Contents:
1 Introduction
Service Manual SIPLACE X-Series S (from Hxxxx) 01/2021 11
1 Introduction
This service guide is a manual or reference work for performing service work on the SIPLACE® X-
Series S placement machines from serial no. Hxxxx onwards.
For additional information, please also observe the instructions for the individual placement heads,
where necessary.
An overview of what is new and of any differences can be found in the following tables:
Serial number from H0001
●
BoxPC 427d
●
CIN box (CAN bus)
●
MGCUs
●
Power supply unit SMPS
●
IOCU 2
●
GigE and new cameras
●
Cable harness and trailing cable interface
Serial number from H1440
●
SIPLACE C&P20P2 in vacuum and ven-
turi mode
●
Multitouch monitor without keyboard
[03211595‑xx] multitouch kit
– Optional 15" monitor and keyboard:
Monitor SCD1520 TDC [03078913‑xx]
Keyboard set [03211595‑xx]
●
Component camera SST48
●
2D track barcode
Barcode set for four locations
[03216618‑xx]
●
Station software 713.0/712.2
SIPLACE Pro 16.1^
●
SIPLACE C&P20P2
Requirements:
– Head interface module C700X-L HR
[03091013-04]
– Head interface module C700X-R HR
[03091023-04]
– Gantry sensor module HCU X‑SeriesS
[03071974‑02]
– Positioning control for the gantry axes
MGCU-3 [03103477‑04]
– Positioning control for the gantry axes
MGCU-2 [03117531‑03]
– X-FCU, 80MHz, 40tracks
[03170613‑xx]
Serial number from H2500
●
New vacuum pump
Vacuum pump Becker VX 4.25 IE3 with cable [03212135Sxx]
