7.0 AX-301/ AX-501 System tree System Tree 26 of 34 PA 1120/02 AX-301 Base incl. Board Support PA 1121/02 AX-501 Base incl. Board Support PA 2108/00 AX-501 2nd UI Monitor PA 2875/00 AX Safety cap PA 1118/15 AX Standard p…
6.0 Installation
requirements
Technical specifications
25 of 34
AX-501 AX-301 AX-201
Maximum height 1905mm (+25 /-0 1905mm (+25 /-0 1905mm (+25 /-0
(incl. light tower) SMEMA) SMEMA) SMEMA)
Topside standard 1290mm (+25 /-0 1290mm (+25 /-0 1290mm (+25 /-0
placement robot SMEMA) SMEMA) SMEMA)
Board transport 940mm (+25 /-0 940mm (+25 /-0 940mm (+25 /-0
SMEMA) SMEMA) SMEMA)
Ambient temperature 15-35°C functions 15-35°C functions 15-35°C functions
guaranteed guaranteed guaranteed
20-28°C specifications 20-28°C specifications 20-28°C specifications
guaranteed guaranteed guaranteed
Humidity 20-90%, no dew 20-90%, no dew 20-90%, no dew
Floor flatness < 1% < 1% < 1%
Power supply 200-480V 3-phase, 200-480V 3-phase, 200-480V 3-phase,
47-63Hz 47-63Hz 47-63Hz
Power consumption 7 kVA 5 kVA 7 kVA
Air supply 6-8 bar, 230 Nl/min 6-8 bar, 150 Nl/min 6-8 bar, 190 Nl/min
(Tape feeding only) (Tape feeding only)
6-8 bar, 290 Nl/min 6-8 bar, 185 NI/min
(Tape & Bulk feeding) (Tape & Bulk feeding)
Width including 2285mm (excl. 2285mm (excl. 2680mm (incl. double
trolleys Extension Module) Extension Module) sided feeding)
Length 3720mm (excl. 2760mm (excl. 1825mm
Extension Module) Extension Module)
Weight (excl trolleys) <3200kg <2500kg <1900kg
7.0 AX-301/
AX-501
System tree
System Tree
26 of 34
PA 1120/02
AX-301 Base
incl. Board Support
PA 1121/02
AX-501 Base
incl. Board Support
PA 2108/00
AX-501 2nd UI Monitor
PA 2875/00
AX Safety cap
PA 1118/15
AX Standard placement
robot
PA 1118/00
AX Compact placement
robot
PA 1865/00
AX Component Vision
PA 1800/00
AX Placement controller
PA 2770/00
AX Toolbit exchange unit
PA 2771/xx
AX Nozzles Lx/Vx
PA 2632/05
A-Series feeder trolley
PA 2681/00
A-Series Tray Trolley
PA 2632/10
A-Series trolley
upgrade air
PA 2648/xx
Twin Bulk Feeder
PA 2654/xx
Tape Feeder ITF-2
PA 2657/00
Twin Tape Feeder 8mm
PA 2632/50
AX Trolley lift cover
A
PA 2634/00
AX Extension Module
PA 2800/00
AX Placement head
Laser Vision
PA 2800/00
AX Placement head
laser
PA 2800/10
AX Placement head
Single Vision
System Tree
27 of 34
PA 2100/**
AX Software release incl. AX Documentation
A
B
PA 3020/10
Performance Data
interface
PA 2280/**
PPS-PRO Front-end
PA 2284/xx
A-Series optimizer/balancer
module
PA 2090/62 SVS Pro AX EUR/APR or
PA 2090/64 SVS Pro AX USA
and/or
PA 2090/21 SVS Pro AX LU
PA 3010/10
Traceability interface
PA 3010/20
Batch traceability
PA 2102/00 AX BTCO Key and/or
PA 2102/05 AX Multilanguage key and/or
PA 2102/10 AX Transport R - L key and/or
PA 2102/20 AX Program editor key and/or
PA 2602/01
Feeder Storage
Cart
9466 920 08361
Small Feeder
Storage Cart
PA 2876/00
AX Calibration set
PA 2876/15
AX 1st level spares kit
PA 2876/40
AX Configuration lift
PA 2876/25
AX Installation tooling
PA 3400/**
AX Documentation ML
(operating manual only)
PA 1122/01
AX-301
Board support
PA 1122/51
AX-501
Board support
AX-301/
AX-501
System tree
PA 2601/01
ITF2 Tape Loading
Unit
PA 2849/30
ITF Analysis &
repair tool
PA 1123/00
AX Board support
preparation kit
PA 1122/31
AX Board support
strip
