Illustrated Parts Manual - XPM 2 Machine System Configuration Sub Assembly Drawing # Parts List Conveyor Belt Only End Assembly Onload 4126201 3126201 End Assembly Offload 4160601 3160601 Rail Only End Assembly Onload 41…
Release Date:
April 5, 2005
Illustrated Parts Manual - XPM
2
The Parts Lists and Exploded Drawings are shown to represent the
most commonly used assemblies on all machines. Optional machine
configurations may include additional or substitute parts and which may
not be listed in this section. Please have oven serial number available
and contact customer service with questions on particular parts or
features that are not listed here.
Conveyor
Electrical
Pneumatics
Cooling
Covers
Cells
Tunnel & Airflow
Exhaust & Filters
Click On Any
Yellow Button or
Highlighted Text
to Navigate
Illustrated Parts Manual - XPM
2
Machine System Configuration Sub Assembly Drawing # Parts List
Conveyor Belt Only End Assembly Onload 4126201 3126201
End Assembly Offload 4160601 3160601
Rail Only End Assembly Onload 4160901 3160901
End Assembly Offload 4161301 3161301
Rail Only & Combo End Plate Left 4177400 3177401
End Plate Right 4177400 3177402
Intermediate Rail 4177500 3177501
Conveyor Picture Intermediate Worm Gear Assembly 4049502 3049502
Intermediate Rail Moving Trolley 4086701 3086701
Intermediate Rail Fixed Trolley 4086801 3086801
Gantry 4178601 3178601
Gantry Trolley 4178501 3178501
End Assembly Onload Combo 4161601 3161601
End Assembly Offload Combo 4161701 3161701
Combo MBS End Assembly Onload Combo MBS 4163301 3163301
Pulley Assembly Onload MBS 4163101 3163101
End Assembly Offload Combo MBS 3163401
Pulley Assembly Onload MBS 4163201 3163201
XCS End Assembly Onload 4182301 3182301
End Assembly Offload 4182201 3182201
ASSY WORM GEAR ON/OFFLD DBL START 4171401 3171401
Intermediate 4181700 3181701
Gantry 4182701 3182701
Transport Accessories
Belts Standard 20" Width 1/2" Pitch 1305500
Standard 24" Width 1/2" Pitch 1461101
Fine Mesh 1458401
MBS Belt 1" x.006" x 46.5" 0989401
MBS Belt 1" x.006" x 36" 0989402
Wear Rods
Rail
Chain
Rail Width Adjust 4090103 3090103
Assy Width Drive Motor 4111401 3111401
Conveyor Drive Motor Standard 3816701
Conveyor Speed Encoder Standard 3162301
Conveyor Options
Conveyor Drive Motor Stepper 3048601
Conveyor Speed Encoder Stepper 3162302
Hand Crank Drawing 3162201
Auto Lube (2 port shown) 4124401 3124401
Assy Transducer Linear (Computerized Rail Width) 3091301
Wear Rod Application Chart
Rail Application Chart
Chain Application Chart
Parts Menu
Machine System Configuration Drawing Part Number/
Parts List
Cell Components All Cells
Motor/Fan 208-240V Assembly View 3100301
Terminal Block 3122801
Washer Carbon Graphite 1390201
Cell Thermocouple 3182401
Connector Thermocouple K Type Female 1299001
Heat Cells
Cool Cells
Heat Exchanger (Upper Only) Part View 3170001
Flux Condensing Fins (Upper Only) Assembly View 3170801
Cell Options
Individual Cell Sensing 3170101
Redundant Over Temperature System 3107304
Illustrated Parts Manual - XPM
2
Heater Panel: Please look at the face plate of the
heater panel for the part number which is stamped
at the location shown in this picture:
