Balloon Quntity Part Number REV DESCRIPTION UM
1 8.00 0856401 SPRKT WIRE BELT 17 TOOTH MBS EA
2 1.00 0863601 SHFT DRIVE BELT/COMBO EA
3 1.00 1001000 SPROCKET IDLER EA
4 1.00 1005400 LINK #35 CHAIN MASTER EA
5 1.00 1007612 SCR 1/2X1-1/2X3/8-16 SHLDR STL EA
6 2.00 1010500 CHAIN #35 DRIVE FT
7 1.00 1010700 CHAIN #35 LINK HALF EA
8 1.00 1012000 NUT 3/8-16 HEX STL FIN EA
9 2.00 1038300 WSHR 3/8 FL A STL EA
10 2.00 1055700 BLANK OFFLOAD EA
11 2.00 1290101 BRG RADIAL .625 BORE EA
12 1.00 1403701 SPRKT #35BS 17-5/8 STL EA
13 1.00 1403702 SPRKT #35BS 18-5/8 STL EA
14 1.00 3161301 B ASSY RAIL OFFLOAD L-R FRONT FIXED EA
BOM NUMBER
3161701
ASSY COMBO OFFLOAD L-R FRONT FIXED 20"
DESCRIPTION
DATE
SHEET
1
REV
B
/ 1
21-Oct-2003
Sort Column = POS
RETURN TO INDEX
3161701
B
4161701
DRAWING NUMBER
REV
B
BCR TYPE
CUR
EXPLODED VIEW DRAWING
Balloon Quntity Part Number REV DESCRIPTION UM
1 2.00 1003908 PIN ROLL 1 INCH EA
3 1.00 6085601 HUB HANDCRANK EA
4 1.00 6085701 HANDLE HANDCRANK EA
BOM NUMBER
3162201
ASSY HANDCRANK
DESCRIPTION
DATE
SHEET
1
REV
A
/ 1
20-May-2003
Sort Column = POS
RETURN TO INDEX
3162201
A
DRAWING NUMBER
REV
BCR TYPE
CUR
EXPLODED VIEW DRAWING
Balloon Quntity Part Number REV DESCRIPTION UM
1.00 0842101 PLT MTG STANDARD ENCODER EA
1.00 0842201 PLT MTG ENCODER PLATE EA
2.00 1012200 WSHR 10 SPLIT LK STL EA
2.00 1171504 SCR 10-32 X .500 BTNH SKT SST EA
4.00 1275700 WSHR 6 SPLIT LOCK SST EA
2.00 1399301 STDF .50DIAX1.063L 1/4-20 THRD EA
1.00 1399201 BRG JRNL FLANGE MNT BRNZ .500 EA
2.00 1013000 WSHR 10 FL B STL EA
2.00 1011700 NUT 10-32 HEX STL FIN EA
2 1.00 1344001 SENSOR ENCODER 1200PPR 5V QUBE EA
4 1.00 0898901 PULLEY 12T RWRK .375 BORE EA
5 1.00 0842401 PULLEY 30T TIMING RWRK .500 BORE EA
7 4.00 1022203 SCR 6-32X3/8 SOCBHD STL EA
8 7.00 1001704 SCR 1/4-20X1/2 SOCCAP STL EA
9 4.00 1012300 WSHR 1/4 SPLT LK STL EA
10 1.00 1283900 CBL CONN 25FT FOR ENCODER EA
12 4.00 1218800 WSHR 6 FL SST EA
13 1.00 1399101 BLT TMNG 1/5 PITCH .25W 10"L EA
BOM NUMBER
3162301
A
SSY CONVEYOR SPEED ENCODER STANDARD
DESCRIPTION
DATE
SHEET
1
REV
B
/ 1
22-Oct-2003
Sort Column = POS
RETURN TO INDEX
3162301
B
DRAWING NUMBER
REV
BCR TYPE
CUR
EXPLODED VIEW DRAWING
