Balloon Quntity Part Number REV DESCRIPTION UM
2.00 6091901 BRKT HEAT EXHCHANGER EA
1.00 6092001 BRKT SHELL OUTER EA
1.00 6092101 BRKT SHELL INNER EA
1.00 6092201 FINS FLUX CONDENSE 27.10 EA
BOM NUMBER
3170801
ASSY FLUX CONDENSE FINS
DESCRIPTION
DATE
SHEET
1
REV
B
/ 1
24-Sep-2003
Sort Column = POS
RETURN TO INDEX
3170801
B
DRAWING NUMBER
REV
BCR TYPE
CUR
DRAWING
Balloon Quntity Part Number REV DESCRIPTION UM
2.00 1012200 WSHR 10 SPLIT LK STL EA
2.00 1082803 SCR 10-32X3/8 PHLPHD STL ZN EA
0.25 1232901 TBG 3/8OD NYL BLK LEGRIS FT
0.25 1232902 TBG 1/2OD NYL BLK LEGRIS FT
2.00 1237410 FTG CONN 1/2T X 3/8MPT LEG EA
2.00 1237502 FTG EL90 3/8T X 3/8MPT LEG PLAS EA
2.00 1240704 FTG NIPPLE CLOSE 3/8MPT BRS EA
1.00 1241104 FTG TEE 3/8FPTX3 BRS EA
1.00 1250103 PLUG 3/8 NPT HEX PIPE SST EA
1.00 1484101 VALVE SOLENOID 3/8FPT SMC EA
1.00 1484501 REGULATOR 3/8/FPT SMC NAR3000-N03BG EA
1.00 1488301 VALVE CHECK INLINE 3/8 TUBE PLASTIC SMC AHK11 EA
1.00 6027512 LABEL N2 CONSERVE REG EA
1.00 6094601 BRKT ALTERNATE PNEU XPM2 EA
1.00 6096201 PLATE WASHER PNEU BRKT XPM2 EA
BOM NUMBER
3176001
ASSY N2 CONSERVATION PIPING STD XPM2
DESCRIPTION
DATE
SHEET
1
REV
A
/ 1
17-Sep-2003
Sort Column = POS
RETURN TO INDEX
3176001
A
4176001
DRAWING NUMBER
REV
A
BCR TYPE
CUR
EXPLODED VIEW DRAWING
Balloon Quntity Part Number REV DESCRIPTION UM
2.00 1012200 WSHR 10 SPLIT LK STL EA
2.00 1082803 SCR 10-32X3/8 PHLPHD STL ZN EA
1.00 1149802 FTG BSHG 3/8MPT X 1/8FPT BRASS EA
0.50 1232901 TBG 3/8OD NYL BLK LEGRIS FT
3.00 1232904 TBG 1/4OD NYL BLK LEGRIS FT
2.00 1237402 FTG 3/8T X 3/8MPT EA
3.00 1237506 FTG EL90 1/4T X 1/8MPT LEG PLAS EA
1.00 1240704 FTG NIPPLE CLOSE 3/8MPT BRS EA
1.00 1240803 FTG NIPPLE 3/8MPT X 2" BRS EA
1.00 1241104 FTG TEE 3/8FPTX3 BRS EA
1.00 1484101 VALVE SOLENOID 3/8FPT SMC EA
1.00 1484401 FILTER/REGULATOR 3/8FPT SMC NAW3000-N03BG EA
1.00 1484701 FTG EL90 ST 3/8FPT X 3/8MPT BRS EA
1.00 1488401 FTG TEE BRANCH 3/8T X 3/8MPT X 3/8T SMC PLAS EA
1.00 1488701 VALVE NEEDLE 1/8 FPT SWAGELOK B-2MG4-MH EA
1.00 1489001 FTG RED EL 90 3/8T MALE X 1/4T SMC PLAS EA
1.00 6027509 LABEL O2 DOPING ADJUST EA
1.00 6027510 LABEL O2 DOPING REG EA
1.00 6094601 BRKT ALTERNATE PNEU XPM2 EA
1.00 6096201 PLATE WASHER PNEU BRKT XPM2 EA
BOM NUMBER
3176101
ASSY O2 DOPING STD XPM2
DESCRIPTION
DATE
SHEET
1
REV
A
/ 1
30-Sep-2003
Sort Column = POS
RETURN TO INDEX
3176101
A
4176101
DRAWING NUMBER
REV
A
BCR TYPE
CUR
EXPLODED VIEW DRAWING
