Balloon Quntity Part Number REV DESCRIPTION UM 1.00 1117200 TRIM VINYL EDGE FT 1.00 6041801 BRACKET CABLE SPPRT COOL MOD EA 1.00 6043701 A COVER INSUL FRONT RESERVOIR EA 0.00 6044001 TEMPLATE INSUL FRONT RESERVOIR EA 0.0…

100%1 / 161
Balloon Quntity Part Number REV DESCRIPTION UM
01 4.00 1011604 SCR 10-32X1/2 SOCBHD STL EA
02 2.00 1011606 SCR 10-32X3/4 SOCBHD STL EA
03 6.00 1011700 NUT 10-32 HEX STL FIN EA
04 6.00 1012200 WSHR 10 SPLIT LK STL EA
05 6.00 1013000 WSHR 10 FL B STL EA
06 12.00 1038100 WSHR 8 SPLT LK STL EA
07 12.00 1130500 NUT 8-32 HEX SST EA
08 16.00 1046700 WSHR 8 FL B STL EA
09 8.00 1141104 SCR 8-32X1/2SOCBHD STL EA
10 4.00 1141106 SCR 8-32X3/4 SOCBHD STL EA
12 1.00 1389101 FAN 8IN 115VAC EA
13 1.00 1456401 HEAT EXCHANGER 1/2" TUBE EA
15 1.00 6032401 BRKT FAN MT FRONT PCL EA
16 1.00 6032501 BRKT FAN MT REAR PCL EA
17 1.00 6032601 PLATE FAN MT PCL EA
18 1.00 6032701 SHROUD INLET HX PCL EA
BOM NUMBER
3176401
ASSY EXTERNAL HEAT EXCHANGER XPM2
DESCRIPTION
DATE
SHEET
1
REV
A
/ 1
24-Sep-2003
Sort Column = POS
RETURN TO INDEX
3176401
A
DRAWING NUMBER
REV
BCR TYPE
CUR
EXPLODED VIEW DRAWING
Balloon Quntity Part Number REV DESCRIPTION UM
1.00 1117200 TRIM VINYL EDGE FT
1.00 6041801 BRACKET CABLE SPPRT COOL MOD EA
1.00 6043701 A COVER INSUL FRONT RESERVOIR EA
0.00 6044001 TEMPLATE INSUL FRONT RESERVOIR EA
0.00 6044201 TEMPLATE INSUL HEATER CONTR COOL EA
0.00 6044101 TEMPLATE INSUL REAR RESERVOIR EA
1.00 6043801 A COVER INSUL REAR RESERVOIR EA
01 2.00 1012100 WSHR 3/8 SPLT LK STL EA
02 3.00 1020202 CABLE TIE 8 IN L EA
03 2.00 1024604 SCR 3/8 - 16 X 1/2 HHD STL EA
04 1.00 1234001 FTG EL90 1/2MPT X 1/2FPT BRS EA
05 1.00 1240907 FTG CROSS 1 FPT X 4 BRS EA
06 2.00 1241511 FTG BSHG 1MPT X 1/2FPT BRS EA
07 2.00 1244604 CLAMP SPLIT RING 1" PIPE EA
08 1.00 1446818 FTG BARB 1/2IDX1/2MPT BRS EA
09 1.00 1478803 HOSE SILICONE RUBBER 1/2" I.D. FT
10 1.00 1448713 FTG BARB EL90 1/2IDX1/2MPT BRS EA
11 2.00 1448803 CLAMP HOSE MINI 13-24MM ID EA
12 1.00 1461209 FTG NIP 1MPT X 8LG BRS EA
13 1.00 6043901 A COVER INSUL HEATER CONTR COOL EA
14 1.00 1461701 SWITCH BRASS HI TEMP 105C EA
15 1.00 1461801 HEATER IMM 2000W 240/480VAC EA
16 1.00 1463610 FTG RDC CPLG 1FPT X 1/2FPT BRS EA
BOM NUMBER
3176501
ASSY HEATER CONTROLLED COOLING XPM2
DESCRIPTION
DATE
SHEET
1
REV
A
/ 1
25-Sep-2003
Sort Column = POS
RETURN TO INDEX
3176501
A
4176501
DRAWING NUMBER
REV
A
BCR TYPE
CUR
EXPLODED VIEW DRAWING
Balloon Quntity Part Number REV DESCRIPTION UM
2.00 1011700 NUT 10-32 HEX STL FIN EA
2.00 1012200 WSHR 10 SPLIT LK STL EA
2.00 1013000 WSHR 10 FL B STL EA
1.00 1232904 TBG 1/4OD NYL BLK LEGRIS FT
1.00 1237407 FTG CONN 1/4T X 1/8MPT EA
1.00 1237506 FTG EL90 1/4T X 1/8MPT LEG PLAS EA
2.00 1316404 SCR 10-32X15/8 PHLPHD STL ZN EA
1.00 1467602 SWITCH PRESSURE .55IN SPDT EA
1.00 1486201 FTG BLKHD 1/4T X 1/8FPT SWG BRASS EA
1.00 6095901 TUBE FEED THRU 1/4 OD X 7.00 LG EA
1.00 6096601 BRKT EXHAUST SENSING XPM2 EA
BOM NUMBER
3176701
ASSY EXHAUST SENSING XPM2
DESCRIPTION
DATE
SHEET
1
REV
B
/ 1
04-Dec-2003
Sort Column = POS
RETURN TO INDEX
3176701
B
4176701
DRAWING NUMBER
REV
B
BCR TYPE
CUR
EXPLODED VIEW DRAWING
