Balloon Quntity Part Number REV DESCRIPTION UM 27 2.00 1193200 CHAIN 35 STAINLESS ROLLER FT 28 1.00 1193300 LINK 35 STAINLESS MASTER EA 29 1.00 1336601 CPLG JAW W/BRZ INS 1/2 ID (Seacoast) EA 30 4.00 1343001 BRG PLAIN .5…
Balloon Quntity Part Number REV DESCRIPTION UM
1 2.00 0368000 BEARING THRUST EA
2 2.00 0642601 SPROCKET MODIFIED 10T EA
3 1.00 0792546 INSUL MW UNFCD 25.13X1.88X1.50 EA
4 2.00 0864301 PLT ADAPTER INTER COMBO MBS EA
5 1.00 0864401 GUARD CHAIN INTER LH MBS EA
6 1.00 0864402 GUARD CHAIN INTER RH MBS EA
7 2.00 0864501 PLT BACKUP INTER MBS EA
8 1.00 0956501 SCR ACME 3/4-10RH INTER X-WIDE EA
9 3.00 0956601 SHFT .50 DIA X 29.56 SST EA
10 1.00 0957001 SHFT .50 INTER DRIVE STL PLT EA
11 1.00 0969201 CROSS TIE INTERMEDIATE EA
12 2.00 0969311 INSUL MW UNFCD 31X4X1.5 EA
13 1.00 0973501 PLT MTG 4.0IN INT UPR/LWR EA
14 1.00 0973601 BRIDGE WEAR ROD SPRT 25.25 CMB EA
15 1.00 0978201 SPRT INTER W/ROD BELT/COMBO EA
16 12.00 1001704 SCR 1/4-20X1/2 SOCCAP STL EA
17 1.00 1001708 SCR 1/4-20X1 SOCCAP STL EA
18 1.00 1011900 NUT 1/4-20 HEX STL FIN EA
19 4.00 1012200 WSHR 10 SPLIT LK STL EA
20 11.00 1012300 WSHR 1/4 SPLT LK STL EA
21 10.00 1012500 WSHR 1/4 FL STL EA
22 6.00 1012903 SCR 1/4-20X3/8 SOCSET STL EA
23 2.00 1012906 SCREW 1/4-20X3/4 SET EA
24 0.00 1146300 LOCTITE 272 EA
25 2.00 1159700 WSHR THRUST .500ID X 1.000 OD BZ EA
26 8.00 1171502 SCR 10-32 X .250 BTNH SKT SST EA
BOM NUMBER
3177501
ASSY COMBO/RAIL INT FRONT FIXED XPM2
DESCRIPTION
DATE
SHEET
1
REV
A
/ 2
28-Oct-2003
Sort Column = POS
RETURN TO INDEX
3177501
A
4177500
DRAWING NUMBER
REV
A
BCR TYPE
CUR
EXPLODED VIEW DRAWING
Balloon Quntity Part Number REV DESCRIPTION UM
27 2.00 1193200 CHAIN 35 STAINLESS ROLLER FT
28 1.00 1193300 LINK 35 STAINLESS MASTER EA
29 1.00 1336601 CPLG JAW W/BRZ INS 1/2 ID (Seacoast) EA
30 4.00 1343001 BRG PLAIN .50ID X .875OD X .625L EA
31 2.00 1397802 RING RET EXT PUSH ON .50 SST EA
32 1.00 3086701 B ASSY INTER TROLLEY MOVING EA
33 1.00 3086801 B ASSY INTER TROLLEY FIXED EA
BOM NUMBER
3177501
ASSY COMBO/RAIL INT FRONT FIXED XPM2
DESCRIPTION
DATE
SHEET
2
REV
A
/ 2
28-Oct-2003
Sort Column = POS
3177501
A
4177500
DRAWING NUMBER
REV
A
BCR TYPE
CUR
Balloon Quntity Part Number REV DESCRIPTION UM
1 4.00 0906401 ROLLER 5/8 OD X .191 ID SST EA
2 2.00 0908501 SPACER UPR ROLLER TROLLEY EA
3 2.00 1012200 WSHR 10 SPLIT LK STL EA
4 2.00 1013810 SCR 10-32X1-1/4 PHLRHD STL EA
5 4.00 1084000 SCR 6-32X1/2 PHLPHD SST EA
6 4.00 1412501 PIN CLEVIS .186X 531L SST EA
7 4.00 1466301 HAIRPIN .38DIA .047WIRE SST EA
8 1.00 6098101 BRKT RAIL TOP GANTRY EA
9 1.00 6098201 BRKT RAIL BOTTOM GANTRY EA
10 2.00 6098301 BRKT ROLLER GANTRY EA
BOM NUMBER
3178501
ASSY GANTRY TROLLEY XPM2
DESCRIPTION
DATE
SHEET
1
REV
A
/ 1
14-Nov-2003
Sort Column = POS
RETURN TO INDEX
3178501
A
4178501
DRAWING NUMBER
REV
A
BCR TYPE
CUR
EXPLODED VIEW DRAWING
