Rails & Chains by Machine Size Component Item Description Drawing Part Number Rail ASSY RAIL SINGLE 7 ZN 3044902 ASSY RAIL SINGLE 10 ZN 3044903 ASSY RAIL SINGLE 13 ZN 3044904 ASSY RAIL SINGLE 16 ZN 3044905 Rail Width…
Machine System Part Name Drawing Part Number/
Parts List
Exhaust Components
Kit Stack Filters - Includes 12 each of 1481601 & 1481701 3176201
Filter 1 x 10 x 20 Polyester picture 1481601
Filter 1 x 10 x 20 Sep Pleated picture 1481701
Stack Filter Box 4161100 3161101
Assy Nozzle Controlled Exhaust 4166101 3166101
Assy FFC 10 Zone True Air XPM2 4165700 3165701
Assy Valve FFC N.O. XPM2 4165501 3165501
Assy Valve FFC N.C. XPM2 4165502 3165502
Assy Exhaust Sensing XPM2 4176701 3176701
Illustrated Parts Manual - XPM
2
Parts Menu
Rails & Chains by Machine Size
Component Item Description Drawing Part Number
Rail ASSY RAIL SINGLE 7 ZN 3044902
ASSY RAIL SINGLE 10 ZN 3044903
ASSY RAIL SINGLE 13 ZN 3044904
ASSY RAIL SINGLE 16 ZN 3044905
Rail Width Adjust KIT RAIL WIDTH ADJ 7 ZN 3090102
KIT RAIL WIDTH ADJ 10 ZN 3090103
KIT RAIL WIDTH ADJ 13 ZN 3090104
KIT RAIL WIDTH ADJ 16 ZN 3090105
Part Number/ Part Number/
Quantity Length
Chain (Rail & Combo) CHAIN #35 D-3 .185 PIN STL 1053700
LINK MASTER #35 D-3 .185 PIN STL 1467201
7 Zone 2 50 ft
10 Zone 2 62 ft
13 Zone 2 74 ft
16 Zone 2 86 ft
Chain (MBS) CHAIN CONVEYOR 35X.185 PIN 1002100
LINK #35 CONVEYOR CHAIN MASTER 1025600
7 Zone 2 50 ft
10 Zone 2 62 ft
13 Zone 2 74 ft
16 Zone 2 86 ft
Index
Exploded Views/Part Listing - XPM2
Wear Rods Configuration
Kit #
Wear Rods (Belt Only & Combo) 18-20 Belt Width 22-24 Belt Width
Assy Wear Rod 7 ZN 3 4 3088502
Assy Wear Rod 10 ZN 3 4 3088503
Assy Wear Rod 13 ZN 3 4 3088504
Assy Wear Rod 16 ZN 3 4 3088505
Wear Rods (MBS)
Assy Wear Rod 7 ZN 9 11 3088602
Assy Wear Rod 10 ZN 9 11 3088603
Assy Wear Rod 13 ZN 9 11 3088604
Assy Wear Rod 16 ZN 9 11 3088605
Quantity of Kits Required
Conveyor Index
