Page
SAMSUNG TECHWIN
20
SME
12mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE IT Non-IT Reference
9 S72000013A VINYL SEPARATOR 1 1 ○○
10 S66010005A BEARING 2 ○○
11 S60010002A SHCS 1 ○○
12 S60420001A FLAT WASHER 1 ○○
13 S60010001A SHCS 2 ○○
G S90000018A VINYL EXIT ROLLER ASSY 1 ○○
1 S72000018A TORQUE LIMIT GEAR 1 ○○
2 S70000042A TORQUE LIMIT SHAFT 1 ○○
3 S70000043A TORQUE LIMIT SPRING 1 ○○
4 S70000044A TORQUE LIMIT SHAFT BOLT 1 ○○
H S90000023A VINYL EXIT MOVING ASSY 1 ○○
1 S70000051A MOVING ROLLER HANDLE 1 ○○
2 S70000052A VINYL MOVING SPRING SHAFT 1 1 ○○
3 S70000053A VINYL MOVING ROLLER SHAFT 1 ○○
4 S71000016A VINYL MOVING ROLLER SLEEVE 1 ○○
5 S72000023A VINYL GEAR C_12 1 ○○
6 S72000024A VINYL SEPARATOR 2 1 ○○
7 S60010001A SHCS 2 ○○
I S90000028A SPROCKET SENSOR ASSY 1 ○○
1 S70000058A SPROCKET SENSOR HOLDER 1 ○○
2 S32120001A SPROCKET SENSOR 1 ○○
3 S91000001A SPROCKET SENSOR CABLE 1 ○○
4 S60010001A SHCS 2 ○○
Page
SAMSUNG TECHWIN
21
SME
12mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE IT Non-IT Reference
J J90651523A LOCKER ASSY 1 ○○
K S90000030A TAPE GUIDE ASSY 1 ○○
1 S70000059A VINYL COVER LEVER SPRING 1 ○○
2 S60060001A FHCS 2 ○○
L S90000036A VINYL ADT. ASSY 1 ○○
1 S90000037A VINYL COVER LEVER ASSY 1 ○○
2 S70000062A VINYL ADT. BLOCK 1 ○○
3 S70000063A VINYL COVER LEVER SHAFT 1 ○○
4 S60710001A SNAP RING 1 ○○
M S90000038A TAPE GUIDE SHUTTER ASSY 1 ○○
1 S70000064A VINYL COVER GUIDE PIN 2 ○○
2 S70000065A VINYL COVER SPRING PLATE 1 ○○
3 S70000067A TAPE GUIDE_12 1 ○○
4 S90000044A VINYL MOVING COVER ASSY 1 ○○
N S90000050A AUX. ASSY 1 ○○
1 S71000021A AUX. PLATE 1 ○○
2 S72000033A LINK COVER 1 ○○
3 S70000080A GRIP NUT 1 ○○
4 J7265131A DAMPER 1 ○○
5 J7065802A DAMPER WASHER 1 ○○
6 J9065092A STOPPER ASSY 1 ○○
7-1 S91000002A MAIN BOARD(IT) 1 ○ X
7-2 S91000009A MAIN BOARD(NON-IT) 1 X ○
Page
SAMSUNG TECHWIN
22
SME
12mm SME Tape Feeder - Total
NO. LEVEL PART NO. PART NAME Q'TY TYPE IT Non-IT Reference
8 S91000007A LIMIT SWITCH CABLE ASSY 1 ○○
9 J90600366B IT SLAVE PCB ASSY 1 ○ X
10 S60060004A FHCS 7 ○○
11 S60060002A FHCS 2 ○○
12 S60050001A BHCS 2 ○ X
13 S60050003A BHCS 2 ○○
14 S60250001A NUT 2 ○○
15 S61190002A SUPPORT 2 ○ X
16 S60710003A SNAP RING 2 ○
O S90000056A FEEDER CLAMP ASSY 1 ○○
1 J90651524A CLAMP LEVER ASSY 1 ○○
2 S90000057A T_LINK ASSY 1 ○○
2-1 S90000058A T_LINK2 ASSY 1 ○○
2-2 J70650996B T_LINK1 1 ○○
2-3 J70660007C T_LINK1 SHAFT2 1 ○○
2-4 J70652737A T_LINK3 1 ○○
2-5 J70660002C T_LINK2 SHAFT 2 1 ○○
2-6 J70652736A T_LINK4 1 ○○
2-7 J70660029B T_LINK3 SHAFT1 1 ○○
2-8 S70000084A T_LINK5 1 ○○
2-9 J70652727A T_LINK4 PIN 1 ○○
2-10 S60710003A SNAP RING 1 ○○
2-11 S60710002A SNAP RING 3 ○○
3 S70000083A T_LINK5 SHAFT 1 1 ○○
4 S60710004A SNAP RING 1 ○○
