Pyramax solder reflow ovens are designed
and built to master today’s lead-free processes,
and the challenges of tomorrow. With their
unparalleled combination of thermal perfor-
mance, versatility, and value, they set the industry
standard for world class performance.
Pyramax provides optimized lead-free
processing, boosting productivity and efficiency.
BTU’s exclusive closed loop convection control,
provides precise heating and cooling control,
constant heat transfer, maximum process control
and reduced nitrogen consumption adding up to
the lowest Cost of Ownership in the industry.
With 6, 8, 10 and 12 zone air or nitrogen models,
350ºC maximum temperature, flexible platform
configuration, low nitrogen and power
consumption, and a comprehensive menu
of options, the Pyramax is both the industry’s
most versatile performer and its best value.
Built for Today. Ready for Tomorrow.
•
SMT Reflow
•
Curing
•
Semiconductor
Packaging
Flux Management System
BTU’s patented Flux
Management System traps flux residue from the process cham-
ber, preventing it from settling within the oven,
leading to increased uptime and lower cost-of-ownership.
• Easy access to filtration and trap arrangement
• Multiple extraction locations maximize overall efficiency
• “On the fly” maintenance eliminates downtime
Innovative
Cooling System
BTU’s unique clamshell air
or water-cooling design
moves the cooling media
away from the process chamber, where it can be easily
accessed for maintenance.
• Water cooling features a
sliding heat exchanger
assembly allowing easy
access for maintenance
• Closed loop cooling control provides variable
cooling rates and increased process control
Customer Support
BTU’s quality products are backed by its Industry leading comprehensive warranty.
• Lifetime on heaters and blowers • 3 years system • 1 year labor
To enhance uptime the Pyramax is supported by BTU’s 24-hour, 7-Day Worldwide customer support, and electronic user documentation.
Standard Features
• Lead Free Process-Guaranteed
• 350ºC Maximum Temperature
• Forced Impingement Convection
• Programmable Heating and Cooling Rates
• Side to Side Gas Recirculation
• Low Nitrogen and Power Consumption
• Flexible Platform Configuration
• Automatic Width Adjust
• Dynamic Gas Idle
• Smart Product Tracking (SMEMA)
• WINCON Control Software
• Electronic Over-Temperature Safety System
Options
• 24 in Processing Capability
• 400ºC Maximum Temperature
• Belt and Rail Conveyors
• Fine Mesh Conveyor Belts
• Multiple Track Solution
• Flux Management
• Closed Loop Convection Control
• Integrated Water Supply
• Low Nitrogen Consumption Package
• High Power Heaters
• Center Supports
• Automatic Gas Sampling
• UL 508A and CE Compliant
• Automated Wafer Handling
• Barcode Reader
Lead Free
Process-Guaranteed
BTU’s repeatable process
control eases the transition
to lead-free.
• Stainless steel construction
• 350°C Maximum temperature
• Closed loop convection
control
• Superior cooling performance
Energy Pilot
Energy Pilot software enables
energy savings by using
product tracking technology
to modify oven performance
during gaps in production.
• Reduces Electrical, Air and/or
Nitrogen consumption
during idle.
• 3 idle modes: standby,
sleep, hibernate
• Operation can be configured
from fully automatic to manual
308
258
208
158
108
58
8
0.0 0.7
1.4 2.1 2.8 3.5 4.2 4.9 5.6 6.3
Te mperature (Celsius)
Minutes (slope degrees/second)
LEAD FREE PROFILE
Furnace
Control
Unit
Speed
Controller
Pressure
Tr ansducer
CLOSED LOOP
CONVECTION CONTROL
ENERGY SAVINGS
Hibernate Power
for extended
periods of non
production
Sleep Power
for gaps in
production
Standby Power
for small gaps
in production
Normal
Operating
Power
308
258
208
158
108
58
8
0.0 0.7
1.4 2.1 2.8 3.5 4.2 4.9 5.6 6.3
Te mperature (Celsius)
Minutes (slope degrees/second)
LEAD FREE PROFILE
Furnace
Control
Unit
Speed
Controller
Pressure
Tr ansducer
CLOSED LOOP
CONVECTION CONTROL
Barcode Reader
Closed Loop Convection
BTU’s exclusive Closed Loop Convection Control
provides maximum flexibility in process control.
• Side-to-side recirculation enhances
temperature uniformity
• Guaranteed process repeatability, system to
system, site to site
• Unmatched convection efficiency reduces zone
temperature setpoints.
