Standard Features
• Lead Free Process-Guaranteed
• 350ºC Maximum Temperature
• Forced Impingement Convection
• Programmable Heating and Cooling Rates
• Side to Side Gas Recirculation
• Low Nitrogen and Power Consumption
• Flexible Platform Configuration
• Automatic Width Adjust
• Dynamic Gas Idle
• Smart Product Tracking (SMEMA)
• WINCON Control Software
• Electronic Over-Temperature Safety System
Options
• 24 in Processing Capability
• 400ºC Maximum Temperature
• Belt and Rail Conveyors
• Fine Mesh Conveyor Belts
• Multiple Track Solution
• Flux Management
• Closed Loop Convection Control
• Integrated Water Supply
• Low Nitrogen Consumption Package
• High Power Heaters
• Center Supports
• Automatic Gas Sampling
• UL 508A and CE Compliant
• Automated Wafer Handling
• Barcode Reader
Lead Free
Process-Guaranteed
BTU’s repeatable process
control eases the transition
to lead-free.
• Stainless steel construction
• 350°C Maximum temperature
• Closed loop convection
control
• Superior cooling performance
Energy Pilot
Energy Pilot software enables
energy savings by using
product tracking technology
to modify oven performance
during gaps in production.
• Reduces Electrical, Air and/or
Nitrogen consumption
during idle.
• 3 idle modes: standby,
sleep, hibernate
• Operation can be configured
from fully automatic to manual
308
258
208
158
108
58
8
0.0 0.7
1.4 2.1 2.8 3.5 4.2 4.9 5.6 6.3
Te mperature (Celsius)
Minutes (slope degrees/second)
LEAD FREE PROFILE
Furnace
Control
Unit
Speed
Controller
Pressure
Tr ansducer
CLOSED LOOP
CONVECTION CONTROL
ENERGY SAVINGS
Hibernate Power
for extended
periods of non
production
Sleep Power
for gaps in
production
Standby Power
for small gaps
in production
Normal
Operating
Power
308
258
208
158
108
58
8
0.0 0.7
1.4 2.1 2.8 3.5 4.2 4.9 5.6 6.3
Te mperature (Celsius)
Minutes (slope degrees/second)
LEAD FREE PROFILE
Furnace
Control
Unit
Speed
Controller
Pressure
Tr ansducer
CLOSED LOOP
CONVECTION CONTROL
Barcode Reader
Closed Loop Convection
BTU’s exclusive Closed Loop Convection Control
provides maximum flexibility in process control.
• Side-to-side recirculation enhances
temperature uniformity
• Guaranteed process repeatability, system to
system, site to site
• Unmatched convection efficiency reduces zone
temperature setpoints.
Pyramax Specifications*
Model Pyramax 75A Pyramax 100A Pyramax 100N
Atmosphere Air Air Air or Nitrogen
Conveyor Speed 10-60 in/min 25-152 cm/min 10-60 in/min 25-152 cm/min 10-60 in/min 25-152 cm/min
Conveyor Width 2-18 in 51-457 mm 2-18 in 51-457 mm 2-18 in 51-457 mm
Heated Length 75 in 1905 mm 100 in 2540 mm 100 in 2540 mm
Heated Zones (Top/Bottom) 6 top / 3 bottom 8 top / 8 bottom 8 top / 8 bottom
Cooling Length 24 inches 610 mm 24 in 610 mm 28 in 711 mm
Cooling Zones (Top/Bottom) 1 top (bottom optional) 1 top (bottom optional) 1 top / 1 bottom,
2 top / 2 bottom (optional)
Overall System Length 127in 3226mm 183 in 4648 mm 183 in 4648 mm
Overall System Height 60 in 1524 mm 60 in 1524 mm 60 in 1524 mm
Overall System Width 60 in 1524 mm 60 in 1524 mm 60 in 1524 mm
Voltage Range 208-480 VAC 208-480 VAC 208-480 VAC
Pyramax 125A Pyramax 125N Pyramax 150A z12 Pyramax 150N z12
Air Air or Nitrogen Air Air or Nitrogen
10-60 in/min 25-152 cm/min 10-60 in/min 25-152 cm/min 10-60 in/min 25-152 cm/min 10-60 in/min 25-152 cm/min
2-18 in 51-457 mm 2-18 in 51-457 mm 2-18 in 51-457 mm 2-18 in 51-457 mm
125 in 3175 mm 125 in 3175 mm 150 in 3810 mm 150 in 3810 mm
10 top / 10 bottom 10 top / 10 bottom 12 top / 12 bottom 12 top / 12 bottom
48 in 1219 mm 46 in 1168 mm 48 in 1219 mm 46 in 1168 mm
2 top (bottom optional) 2 top / 2 bottom (optional) 2 top (bottom optional) 2 top / 2 bottom
230 in 5844 mm 230 in 5844 mm 255 in 6474 mm 255 in 6474 mm
60 in 1524 mm 60 in 1524 mm 60 in 1524 mm 60 in 1524 mm
60 in 1524 mm 60 in 1524 mm 60 in 1524 mm 60 in 1524 mm
208-480 VAC 208-480 VAC 208-480 VAC 208-480 VAC
* All specifications are subject to change without notice
