SM471_Technical_RF(Eng_Ver3.2_CS14.16)(1) - 第12页
Page SAMSUNG TECHWIN 4 SM471 F eeder Base Ass'y - ST
Page
SAMSUNG TECHWIN
3
SM471
Mechanical Part
Page
SAMSUNG TECHWIN
4
SM471
Feeder Base Ass'y - ST
Page
SAMSUNG TECHWIN
5
SM471
Feeder Base Ass'y - ST
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
A J90571018A
FEEDER_BASE_ST J90571018A
1
1 FC07-000033B
BLOCK-VERTICAL LOCATOR;ME1:Steel
1
2 J70570262C
CAP-TOP PLATE
5
3 J1301188
FITTING [KQ2L04-M5/PL4-M5M/SQL04-M5]
2
4 FC05-000122A
BASE-SM411_FEEDER_BASE_BODY2;GCD 450-10
1
5 J7057213A SIDE CABLE COVER-FB[J7057213A] 2
6 J90600351B FEEDERBASE_LEFT_COVER_PCB_ND 1
7 AM03-000694A
ASSY,BOARD-FBLN
1
8 J90600352B
FEEDERBASE_RIGHT_COVER_PCB_ND
1
9 AM03-000693A
ASSY,BOARD-FBRN
1
10 J1300399
BUTTON HEAD SOCKET SCREW M3*6 (SUS)
6
11 J60190308A FLAT_HEAD_CROSS_SCREW M3*8_BLACK 32
12 J6001501538
SOCKET HEAD CAP SCREW M5*15 (NI/ZN)
24
13 J67111148A
COUPLER TCP1B10-15A-R8036
60
14 J6001802038
SOCKET HEAD CAP SCREW M8*20 (NI/ZN)
7
15 FC09-000901C BRACKET-Top_Plate_S 1 FC09-000901A
16 FC09-001200C
BRACKET-TOP-PLATE-BACK-HOLE
1 FC09-001200A
