Page SAMSUNG TECHWIN 31 SM471 C onveyor Ass'y (5/6) NO. Lev . P ART NO. P ART NAME Q'TY Old No. Supply Supply L T Reference
Page
SAMSUNG TECHWIN
30
SM471
Conveyor Ass'y (5/6)
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
28 FC30-001359A
PLATE-STOPPER_TOP_SMC-CYL;SS400
1 J70531050A
29 J70531029B STOPPER_POST 1 J70531029A
30 J70531014B SUPPORT_FIX_RAIL_LEFT 1 J70531014A
31 J70531013A SUPPORT_FIX_RAIL_RIGHT J70531013A 1
32 J70531012C SUPPORT_MOVE_RAIL_TL 1 J70531012B
33 J70531011A SUPPORT_MOVE_RAIL_TR J70531011A 1
34 J70531028A TENSION_BEARING_PIN J70531028A 2
35 J70531027A TENSION_BRACKET J70531027A 2
36 J66021007A TIMMING_BELT_WIDTH 180-3GT-9 1
37 J71531008A PULLEY_W_MOTOR J71531008A 1
38 J71531024A WIDTH_PULLEY J71531024A 8
39 J70531066A WORK_WIDTH_SENSOR_DOG J70531066A 1
40 J66021006A BELT_WORK MAM-5P-1550-6W 2
41 J71531013B
WORK_FRONT_FRAME
2
42 EP03-000170 CABLE_VEYOR HSP0130-1B-18R-28LINK 1 J65041004A
43 J6073010136H C-RING DIA11(HOLE) 8 J6073000036H
44 J70531103A CV_SUPPORT_M_RAIL J70531103A 1
45 EP08-000203 SERVO_MOTOR_PB PBM423DXC24 1 J31081004A
46 J31041014A STEP_MOTOR 2S56Q-01842SR2 1
47 J3211048A PHOTO SENSOR[E3S-LS3N] 2
48 HP03-000094 CYLINDER-CXSJM10-30-A93 1 J6701018B
49 2
50 1
51 J70531027A
TENSION_BRACKET J70531027A
2
Page
SAMSUNG TECHWIN
31
SM471
Conveyor Ass'y (5/6)
NO. Lev. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
Page
SAMSUNG TECHWIN
32
SM471
Conveyor Ass'y (6/6)
3
3
4
5
4
5
6
8
8
7
1
7
1
7
1
2
AIR SHOWER OPTION
1
7
2
AIR SHOWER OPTION
