M6e_ServiceManual_e.pdf - 第75页
5 Materials 5-1 5 Materials Standard Accessories Replacement Parts
4 Electrical Section
4-8
Cautions about overall electrical items
Once rats enter indoors or buildings, they easily get into machines. They may tear wirings and leave
excrement that can cause serious damage to machines.
If rats tear wirings, it may cause short circuits. And it could cause a serious problem to machines.
If rats leave excrement over printed circuits boards or bared cables, it will be carbonized and may cause
fire.
REFERENCE:
Below is an example we had fire from a board. (See the pictures below.)
You can see blue-green attached material on the burnt location.
When copper burns, Cuo (copper oxide II) is black and Cu2O (copper oxide I) is red. According to the
blue-green color, the attached material can be considered Copper hydroxide. By this fact, we suppose water
existed on the burnt location.
Blue-green
attachments
COUNTERMEASURE:
1．Keep the room clean, neat and organized.
2．Lock up the room with no openings.
If once rats came in;
3．Sprinkle rat repellent.
4．Catch rats with adhesive sheets. (Emergency countermeasure)
5．Hire an rat exterminator.
To prevent damage caused by rats, it is important to keep rats-free environment.
If already rats are in your space, exterminate them by using rat repellent or other ways as mentioned above.
5 Materials
5-1
5
Materials
Standard Accessories
Replacement Parts
5 Materials
5-2
Standard Accessories
Part Name Part No. Qty. Remarks
NOZ.P031 ASSY. LC6-M7712-00X
NOZ.P032 ASSY. LC6-M7714-00X
NOZ.P033 ASSY. LC6-M7716-00X
NOZ.P034 ASSY. LC6-M7718-00X
NOZ.P005 ASSY. LC6-M7709-00X
NOZ.P006 ASSY. LC6-M770B-00X
NOZ.P012 ASSY. LC6-M770D-00X
NOZ.P013 ASSY. LC6-M770F-00X
NOZ.P017 ASSY. LC6-M770H-00X
NOZ.P018 ASSY. LC6-M770K-00X
NOZ.P019 ASSY. LC6-M770M-00X
NOZ.P020 ASSY. LC6-M770P-00X
NOZ.P042 ASSY. LC6-M7724-00X
Six arbitrary nozzle assemblies
are supplied as standard
accessory.
ID SEAL P031 LC6-M77DG-00X
ID SEAL P032 LC6-M77DH-00X
ID SEAL P033 LC6-M77DJ-00X
ID SEAL P034 LC6-M77DK-00X
ID SEAL P005 LC6-M77D5-00X
ID SEAL P006 LC6-M77D6-00X
ID SEAL P012 LC6-M77D7-00X
ID SEAL P013 LC6-M77D8-00X
ID SEAL P017 LC6-M77D9-00X
ID SEAL P018 LC6-M77DA-00X
ID SEAL P019 LC6-M77DB-00X
ID SEAL P020 LC6-M77DC-00X
ID SEAL P042 LC6-M77DM-00X
One ID sticker is supplied as a
spare for each nozzle.
