Single Conveyor L800(2/3)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
32 J7053048A IDLER SPACER-M 3
33 J70531083A ALT_MOTOR_SUPPORT 4
34 J70531763A BRACKET_BELT_MOTOR_B 1
35 FC09-006192A BRACKET-STOPPER_CYL_L 1
36 J70531765A WORK_SENSOR_BKT 1
37 HP03-900036 AIR CYLINDER 1
38 J70531643A H30_STOPPER_BAR 1
39 P14-900083 THROTTLE VALVE(ELBOW) 1
40 HP06-900010 ELBOW FITTING 1
41 J71531268A CLAMP_FRONT_FRAME 1
42 MC13-900013 LM SLIDE 2
43 J7153036A SLIDE GUIDE 1
44 FC29-004426A STOPPER-CLAMP_SHAFT_STOPPER 2
45 FC01-000022A ADJUSTER-SHAFT_CONV 2
46 MC06-900006 BALL_BUSH 4
47 FC18-001480A SPACER-BUSH_CONVEYOR 2
48 J7153034A CLAMP SHAFT 2
49 MC05-001004 BELT 1
50 MC05-900130 FLAT_BELT_WORK_MOVE_750 1
51 MC05-000254 BELT 1
Page
+$1:+$
171
DECAN
L2
Page
+$1:+$
172
DECAN
L2
Single Conveyor L800(3/3)
