Full Dual Conveyor (9/12)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
32 EP08-000243 MOTOR,STEP 1 EP08-000203
33 J71531008A PULLEY_W_MOTOR 1
34 MC05-900058 TIMMING_BELT 1
35 J70531074A WORK_BELT_MOTOR_BRACKET 1
36 MC19-001136A PULLEY_B_M 1 J71531009A
37 AM03-011143A CABLE ASSY-BELT MOTOR(BW2-2) 1
38 J70531014B SUPPORT_FIX_RAIL_LEFT 1
39 J70531021A IDLER_SHAFT_M 4
40 J71531007A PULLEY_WIDTH_MOTOR 1
41 MC05-001040 TIMING BELT 1
42 J70531019A IDLER_SPACER_13 3
43 FC18-901355 C-RING 2
44 FC18-900900 HEX NUT 2
Page
+$1:+$
79
DECAN
L2
Page
+$1:+$
80
DECAN
L2
Full Dual Conveyor (10/12)
