YESTECH’s advanced multiple color camera imaging
technology offers high-speed PCB inspection with
exceptional defect coverage. With dual sided top-down and
bottom up viewing cameras, the FX-942 inspects solder
joints and verifies correct part assembly enabling users to
improve quality and enhance yields.
Advanced Fusion Lighting and newly available image
processing technology integrates several techniques,
including, color inspection, normalized correlation and
rule-based algorithms, to provide complete inspection
coverage with an unmatched low false failure rate.
Programming the FX-942 is fast and intuitive.
Operators typically take less than 30 minutes to create a
complete inspection program including solder inspection.
The FX-942 utilizes a standard package library to
simplify training and ensure program portability across
manufacturing lines.
The FX-942 is highly effective for selective solder, post wave
and connector inspections. Off-line programming maximizes
machine utilization and real-time SPC monitoring provides a
valuable yield enhancement solution.
Features:
n Dual sided imaging with full travel
imaging sensors
n 1 vertical and 4 optional angle cameras
per side
n Up to 100 mm clearance
n High speed inspection and transfer
n High defect coverage / low false failure
n Picture in Picture (P-in-P) feature
n MES / Industry 4.0 compatible
Automated Inspection for:
n THT component and solder defects
n SMT component presence and position
n Wave / Selective solder joint inspection
n Correct part / polarity
YESTECH FX-942 AOI
In-line dual sided optical inspection
NES_YT-FX-942_DS_9-2020B.qxp_Layout 1 9/4/20 1:12 PM Page 1
For more information,
speak with your
Nordson representative
or contact your Nordson
regional office.
YESTECH
USA Headquarters:
2747 Loker Ave. West
Carlsbad, CA USA 92010
+1.760.918.8471 Phone
+1.760.918.8472 Fax
China:
#137 Guoshoujing Road
Zhangjiang Hi-Tech Park
Pudong,
Shanghai 201203, P.R.China
+86 21 3866 9166 Phone
+86 21 3866 9199 Fax
SE Asia:
2 Corporation Road
#03-11/12
Corporation Place 618494
Singapore
+65 6552 7533 Phone
+65 6552 7116 Fax
Europe:
25 Faraday Road
Rabans Lane Industrial Area
Aylesbury
Buckinghamshire
HP19 8RY
+44 (0) 1296 317800
Phone
+44 (0) 1296 317801 Fax
Japan:
Yamatane Fukagawa No. 1 Bldg.,
1-1-1 Etchujima, Kotu-ku
Tokyo, 135-0044
+81 3 5639 7020 Phone
+81 3 5639 7021 Fax
2747 Loker Ave. West
Carlsbad, CA USA 92010
sales@nordsonyestech.com
+1.760.918.8471 Phone
+1.760.918.8472 Fax
www.nordson-es.com
Copyright © 2020 YESTECH
Specifications
Model
FX-942
Multi-function system with top-down and bottom up
viewing with optional 4 side camera inspection
Optional Upgrades: Laser Height point measurement
Specifications
Throughput: Up to 30 sq. in./sec. > 1.5 million components per
Maximum Board Size: 23” x 16” (580mm x 410mm)
Maximum Inspection Area: 19.5” x 15.5” (495mm x 395mm)
Clearance: 4” (100mm) top size and 2” (50mm) bottom
Minimum Component Size: 01005 with high magnification option
False Calls: <500 PPM (<0.05% typical)
Defects Detected: Part: position, missing, wrong, polarity,
skew, tombstone
Lead: bent, lifted, bridging, pin measurement
Solder: open, insufficient, short, solder balls
Connectors: pin inspection
Software
Algorithms: Color, OCV, OCR, barcode recognition, both image and
rule-based algorithms. Optional 3D
Data Requirements: ASCII Text, X-Y position, part #, ref. #, polarity
CAD Translation Package: Aegis, Fabmaster, YESTECH CAD Utility
Programming Skill Level: Technician or operator
Operating System: Windows 10
Off-line Software: Optional - Rework, Review and Program Creation Basic
SPC Software: SPC included - Optional: Real-time local and remote
monitoring of first pass yield, defect trends, and
machine utilization.
Data Outputs: Text, SQL, ODBC, MS Access, XML
Hardware
Material Handling: SMEMA, dual direction auto width conveyor,
pass / fail signals, board clamping
Lighting: Proprietary Fusion Lighting
™
multiangle LED
Imager: Up to 5 megapixel color camera on each side using
22, 12 or 8 micron pixel size
Facilities
Power: 110-220VAC, 50/60 Hz, 15 amps
Air input: 60 PSI min., 1/4” air hose, 2 CFM
Footprint: 39” x 52” x 60” (1000mm x 1329mm x 1531mm)
Weight: 950 lbs (430 kg)
Machine Installation: < 1 hour
