CUKYX-193-5100_G5S2 - 第110页
193-5100 CUKYX 1.5 侧面视觉板面板 3-17 1.5 侧面视觉板面板 Symbol Name Remarks U02 Side View I/O PCB Model UC39 G9 Side View Camera Power Unit U02 G9 16 3-17A
193-5100
CUKYX
1.4 后侧
3-16
1.4.5 真空泵
Symbol Name Remarks
M66 Vacuum pump Motor
M66
14
3-16A
193-5100
CUKYX
1.5 侧面视觉板面板
3-17
1.5 侧面视觉板面板
Symbol Name Remarks
U02 Side View I/O PCB Model UC39
G9 Side View Camera Power Unit
U02
G9
16
3-17A
193-5100
CUKYX
1.6 侧面面板前侧
3-18
1.6 侧面面板前侧
1.6.1 面板内侧
Symbol Name Remarks
Q205 CirCuit Protector Vacuum pump
Q206 CirCuit Protector
Q221 CirCuit Protector
K29 EM-CONTACTOR Vacuum pump Power Supply
K28 EM-CONTACTOR CPU Power Supply
K10 EM-CONTACTOR G2 Power Supply
K10K28K29Q205
Q206(30A)
Q221(30A)
TB:AC2
3
3-19A
