193-5100 CUKYX 1.8 送料器安装台 1-9 1.8 送料器安装台 No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty 1 Tube ∅ 6 1 2 Solenoid V alve 2 3 Speed Controller 4 4 Cylinder 2 5 Modular Unit 2 6 Air Connector Pin 2 5 1 2 3 4 6 From …
193-5100
CUKYX
1.7 安装头部
1-8
1.7 安装头部
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
∅
4 1
2 Tube
∅
8 1
3 Solenoid Valve 1
4 Rotary Joint 1
5 Solenoid Valve 15
6 Filter 15
A
V
P
R
A
P
A
V
P
A
V
P
Valve
Filter
Rotary Joint
φ8 Fitting
φ8
φ4
φ8 Fitting
φ6 Fitting
φ4 Fitting
φ4 Fitting
Valve
3
2
1
4
5
6
From Main Body
Robot Cable
Nozzle1 Nozzle2 Nozzle15
Fig_1-15S
193-5100
CUKYX
1.8 送料器安装台
1-9
1.8 送料器安装台
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
∅
6 1
2 Solenoid Valve 2
3 Speed Controller 4
4 Cylinder 2
5 Modular Unit 2
6 Air Connector Pin 2
5
1
2
3
4
6
From Main Body
Fig_1-17S
193-5100
CUKYX
1.9 多功能安装头部
1-10
1.9 多功能安装头部
No. Name Q’ty No. Name Q’ty No. Name Q’ty No. Name Q’ty
1 Tube
∅
6 1 11 Union Y 1
2 Tube
∅
6 1 12 Manifold Unit 1
3 Tube
∅
6 1 13 Solenoid Valve Unit 3
4 Tube
∅
6 1 14 Vacuum Filter 3
5 Tube
∅
6 3 15 Robot Cable 3
6 Tube
∅
6 3
7 Tube
∅
6 3
8 Tube
∅
8 1
9 Tube
∅
4 3
10 Regulator 1
Nozzle 3
5
6
7
14
9
13
15
SETUP
0.025MPa
2
3
1
Air IN
Vacuum
11
Nozzle 1
5
6
7
10
8
12
14
9
13
15
Nozzle 2
5
6
7
14
9
13
15
Fig_1-19SA
