35 Sample Configuration Services As a service, SIEMENS A&D EA can fully in tegrate the SIPLACE D 3 plac ement machine into your produc- tion line. With our extensive expertise and by using the right tools an d equipm…

Vision Sensor Technology

Bad Board Recognition

Position Recognition for Feeder Modules

Ink Spot Criteria

Methods • Synthetic fiducial recognition

method

• Mean grayscale value

• Histogram method

• Template matching

Shapes and sizes of fiducials/

structures for

synthetic fiducials

other methods

For dimensions of synthetic fidu-

cials, see page 33

min. 0.3 mm

max. 5 mm

Masking material good coverage

Recognition time depends on the method:

20 ms - 0.2s

Description

In the cluster technology

each subpanel is assigned an

ink spot. If this is present dur-

ing the measurement via the

PCB vision module, the corre-

sponding subpanel is popu-

lated.

It is also possible to accom-

plish the population of the

subpanel when the ink spot is

missing. With this function it

is possible to eliminate costs

due to unnecessary popula-

tion of faulty subpanels.

Global Ink Spot

Each GOOD/SCRAP scan takes

some time, and the time re-

quired is even greater if there

are a large number of sub-

panels on a PCB. Using the

global ink spot can result in a

significant reduction of these

secondary times.

The PCB vision module

searches at positions taught

before for the defined fidu-

cial. In case of recognition

there is no following evalua-

tion of subpanels. The sys-

tem allows the operator to

choose also the reverse inter-

pretation.

Recognition of the position

of the feeder modules

The pick-up position of the

components can be deter-

mined precisely with the aid

of the position recognition

for the feeder. The offset in

position relative to the stored

ideal position is determined

on the basis of fiducials on

the feeder modules using the

PCB vision module. This pro-

vides very high pick-up reli-

ability even for the very first

component, which is particu-

larly important for small com-

ponents.

Sample Configuration

Services

As a service, SIEMENS A&D

EA can fully integrate the

SIPLACE D3 placement

machine into your produc-

tion line. With our extensive

expertise and by using the

right tools and equipment,

we can ensure that the instal-

lation process runs smoothly

and efficiently. However, this

will require you to clarify the

infrastructure aspects in ad-

vance and make any neces-

sary changes at your

production facility.

Safety instructions

Read the operating instruc-

tions before starting to set up

and commission the place-

ment machine. The applica-

ble accident prevention

regulations concerning the

transportation of heavy

goods must be followed.

Nozzle changer C&P12

Component

changeover table

with 15 locations

Nozzle Changer (TwinHead)

5-part conveyor belt

with automatic width adjustment

from 50 mm to 508 mm (2“ to 20“)

Nozzle Changer (TwinHead)

Component

changeover table

with 15 locations

Nozzle changer C&P12

Component changeover table

with 15 locations

C&P12

Technical Data

Siemens Signal Interface

Connector Assignment

Signal interface (20-pole ribbon cable connector)

Upstream station X1 Downstream station X2

Pin 1 Reserved Pin 1 Reserved

Pin 2 GND 24 VDC Pin 2 Reserved

Pin 3 + 24 VDC Pin 3 Reserved

Pin 4 Reserved Pin 4 Reserved

Pin 5 Reserved Pin 5 GND 24 VDC

Pin 6 Reserved Pin 6 + 24 VDC

Pin 7 Reserved Pin 7 Reserved

Pin 8 Reserved Pin 8 Reserved

Pin 9 Reserved Pin 9 Reserved

Pin 10 Reserved Pin 10 Reserved

Pin 11 Interfering signal loop Pin 11 Interfering signal loop

Pin 12 Interfering signal loop Pin 12 Interfering signal loop

Pin 13 GND 24 VDC Pin 13 GND 24 VDC for permission / arrived

(galvanic isolation)

Pin 14 Arrived Pin 14 Arrived

Pin 15 Permission Pin 15 Permission

Pin 16 Reserved Pin 16 Reserved

Pin 17 Reserved Pin 17 Reserved

Pin 18 Transferred Pin 18 Transferred

Pin 19 Request Pin 19 Request

Pin 20 GND 24 VDC for request / transferred

(galvanic isolation)

Pin 20 GND 24 VDC
