48
Technical Data
Transport and Delivery Configuration
Description
The placement machine is
supplied in a wooden crate,
mounted on a stable wooden
pallet.
Configuration when de-
livered
• The extension kit on the
PCB input side and the
computer unit are discon-
nected from the basic ma-
chine.
• All electrical cables to the
basic machine are discon-
nected.
• The conveyor track on the
single conveyor is set to a
width of 210 mm. In a dual
conveyor system, conveyor
track 1 is 100 mm wide,
track 2 210 mm.
• The input conveyors of the
single and dual conveyor
are dismantled. The electri-
cal cables to the conveyor
motors and light barriers
are disconnected.
• Both keyboards and the
monitors are disconnect-
ed.
• The main fault indicator is
dismantled.
Engagement point
for the fork-lift
Engagement point
for the fork-lift
Transport dimensions and weight
Means of transport
A fork-lift truck with the following specification will be needed
to carry the machine in its crate:
Length
Width
Height
2404 mm
2790 mm
1600 mm
Dispatch within Europe Dispatch overseas
Weight 3980 kg 4420 kg
Fork length
Lifting power
Clear fork width
min. 1800 mm
min. 6000 kg
min. 350 mm
49
Option List for the SIPLACE D3
Available options Notes
Transport height (900, 930, 950) X
Single conveyor, stationary side right X
Single conveyor, stationary side left X
Dual conveyor, fixed side right X
Dual conveyor, fixed side left X
PCB alignment, single conveyor X
PCB alignment, dual conveyor X
Long board option X
Wide board configuration X
PCB barcode scanner, 1D X
PCB barcode scanner, 2D X
PCB barcode scanner, assembly kit X
Magnetic pin support X
12-nozzle Collect & amp;Place head X
High-resolution component camera, type 29 (for C&P12) X
Component sensor, C&P12 X
01005 package
a
X
0201 package X
6-nozzle Collect & Place head X
TwinHead X in placement area 2 only
Stationary P&P component camera, type 25, 16 x 16, digital X for the TwinHead only
Coplanarity module X for the TwinHead only (at location 3)
Nozzle changer (according to the head) X
Nozzle changer, 2nd row (depends on head) X
Reject bin sensor X
SIPLACE component changeover table X
Dip module X
External power supply for the component changeover table X
Compressed air distributor, bulk case feeder modules X
Tape reel holder, 3 x 8 mm feeder module, V2 X
Tape reel holder adapter plate X
Feeder module cover flap X
Feeder module fixing X
Waffle-pack tray holder X can also be used at locations 2 and 4
Setup Center
b
X
Splice detection, table controller
b
X
110/208 V conversion kit X
Vacuum pump X not possible on the TwinHead
Vacuum pump connection kit X
SIPLACE matrix tray changer (MTC2) X at location 2 only
Productivity lift X max. PCB width: Single track 460 mm
Double track 216 mm
max. CO height: 17 mm on the underfloor section
a) from 04/2007
b) from 09/2006
