2-1 1 AJQEPED-ID 0606-005 Layout of Sensors and Loads Positioning Layout of Sensors and Loads Positioning Symbol Name Symbol Name -B0508 Lifted Feeder Detection (A) -B0913 Lifting Section Feeder Base Detection 2 -B0509 L…
2-10
AJQEPED-ID
Layout of Sensors and Loads Feeder Bases
0606-005
Layout of Sensors and Loads Feeder Bases
Symbol Name Symbol Name
-B6950 Feeder Clamp Lower Limit
-B6951 Feeder Clamp Upper Limit
-Y6930 Feeder Clamp
2-11
AJQEPED-ID
0606-005
Layout of Sensors and Loads Positioning
Layout of Sensors and Loads Positioning
Symbol Name Symbol Name
-B0508 Lifted Feeder Detection (A) -B0913 Lifting Section Feeder Base Detection 2
-B0509 Lifted Feeder Detection (B) -B0914 Cylinder Upper Limit Detection
-B0510 Lifted Suppressor Detection -B0915 Cylinder Lower Limit Detection
-B0910
Feeder Base Y Direction Positioning Check 1
-B0932 Feeder Base Ascending
-B0911
Feeder Base Y Direction Positioning Check 2
-B0933 Feeder Base Descending
-B0912 Lifting Section Feeder Base Detection 1
2-12
AJQEPED-ID
Layout of Sensors and Loads Nozzle Stockers
0606-005
Layout of Sensors and Loads Nozzle Stockers
Symbol Name Symbol Name
-B0918 Nozzle Stocker Lower Limit Detection 1
-B0920 Nozzle Stocker Shutter Open Check 1
-B0922 Nozzle Stocker Clamp Check 1
-Y0935 Nozzle Stocker Shutter Open
-Y0936 Nozzle Stocker
Ascending 1
