Service Work
Placement Heads White Balance Process for SIPLACE Digital Vision Camera
104 Servicemanual (internal version) SIPLACE D Series
4.2.3.7 Parameter Entries
The XML files which are available at the (start) end of calibration have the following parameters:.
CameraData_36_KL-U5-0003_Gantry1.xml
is the report file for the camera data. This can be read
out of the camera EPROM, before starting calibration.
FCCS.. date .time .xml
is the results file for the camera data. This can be viewed in the camera
EPROM, after Field Camera Calibration Service (FCCS).
Parameter name Value of camera Comments
<?xml version="1.0" encoding="Windows-1252" ?>
- <Sensor system version
="1.0"> Camera version
<General SensorSystemType ="29" Component camera type (here for C&P 6 placement
head)
MaterialNumber ="3018637-02"
SerialNumber ="KL-U5-0013" /> Camera serial number ( also on the camera label)
<Camera Type ="iX20-K01" CCD sensor type
Version ="VER 0002"
SerialNumber ="0055.10.06" />
<Firmware Firmware versions which are "downloadable" with
SITEST
Application ="0.5.03.02"
BIOS ="0.5.03.CF" />
- <Calibration
FirstCalibration ="22.5.2006" Calibration date during manufacture
LastCalibration ="25.10.2006" Sate of current –, last calibration.
TypeOfLastCalibration ="20" 1 Brightness calibration for production / 20 –calibration
in the application on site
NumberOfCalibrations ="2"> Counter status of all complete calibrations (saved in
the camera EPROM)
<CameraPosition Position of stationary camera in X/Y machine
coordinate system
x_mm ="0.000"
y_mm ="0.000"
Angle_degrees ="-90.00" /> Camera angle in the machine
<FocusHeight
z_mm ="14.833" />
<Illumination Brightness values of illumination levels after the white
balance process.
Plane1 ="123" Camera-specific illumination levels
Plane2 ="126" > Values should be similar
> The values divided by the Camera Gain factor are
typically under one hundred.
Plane3 ="117"
Plane4 ="140"
Plane5 ="129"
Plane6 ="0" Levels with ‘0’ are not installed for the respective
camera type.
CameraGain ="2.925" Camera amplification factor
Service Work
White Balance Process for SIPLACE Digital Vision Camera Placement Heads
Servicemanual (internal version) SIPLACE D Series
105
DeadTime ="48800" />
<Shading Status ="0"
ShadingFactorX0 ="0.000000"
ShadingFactorX1 ="0.000000"
ShadingFactorX2 ="0.000000"
ShadingFactorX3 ="0.000000"
ShadingFactorX4 ="0.000000" />
<DefaultScale
x_nm ="26683" Default pixel size from construction
y_nm ="26710" Default pixel size from construction
StateX ="2" />
<CurrentScale
x_nm ="26741" Measured pixel size
y_nm ="26772" /> Measured pixel size
</Calibration>
<Statistics
NumberOfFlashes ="0"
NumberOfBootUps ="262" />
<Diagnostics
StateOfGSM ="4"
LastError ="00" />
<HardwareState
ChecksumEEPROM ="OK"
Selftest ="OK" />
- <SensorSpecificData
PixelScale ="124">
<FieldOfView
StartX ="204"
StartY ="8"
SizeX ="1220" No. of pixels (image points) per line in field of vision
SizeY ="1220" /> No. of pixels (image points) per column in field of vision
<Extended
MaxIllum ="10"
MinSleep ="10"
ModusTrigger ="4"
ModusTransmit ="0"
ModusEnable ="2"
ModusSense ="12"
ModusExposure ="5"
Can0ToPlane ="1"
Can1ToPlane ="2"
Parameter name Value of camera Comments
Service Work
Placement Heads White Balance Process for SIPLACE Digital Vision Camera
106 Servicemanual (internal version) SIPLACE D Series
Can2ToPlane ="4"
Can3ToPlane ="8"
Can4ToPlane ="16"
Can5ToPlane ="32"
FlashDelay ="0"
FinishDelay ="0"
ModusFlash ="0"
TriggerExposure ="20"
MaxExposure ="200" />
</SensorSpecificData>
</Sensorsystem>
