Cable trees
Page 15 / 18 18.11.2021
Cable trees
Page 16 / 18 18.11.2021
Pos. Item no. Description Part marking
00305809-02 CABLE: MAIN ERROR DISPLAY
103 00321474-02 CABLE POWER SUPPLY
124 00328858-01 CABLE : TERMINAL BOARD - OVERV.
PROTEC.
125 00328857-01 CABLE : TERMINAL BOARD -
CIRCUIT BREAKER
131 00317600-02 CABLE: MOTOR / TACHO X-AXIS
132 00317606-02 CABLE: MOTOR / TACHO Z1-AXIS
133 00317610-02 CABLE: MOTOR / TACHO Z3-AXIS
134 00317608-02 CABLE: MOTOR / TACHO Z2-AXIS
135 00317602-02 CABLE: MOTOR / TACHO KX-AXIS
136 00320805-02 CABLE: I/O INTERWIRING BOARD
137 00317604-02 CABLE: MOTOR / TACHO KY-AXIS
138 00317598-02 CABLE: MOTOR / TACHO Y-AXIS
139 00306898-03 CABLE CONTROL UNIT -
CONVERSION BOARD
140 00306882-03 CABLE TERMINAL FIELD
CONVERS.PCB PORTAL
141 00310113-03 CABLE SERIAL I/O G2
142 00306881-04 CABLE CONTROL UNIT -
CONVERSION BOARD
143 00307439-02 CABLE: CRASH-BEROS
144 00307355-02 CABLE CONTROL BOARD -
PNEUMATIC
145 00308527-02 CABLE CONTROL BOARD -
CONVERSION BOARD
146 00308693-03 CABEL TERMINAL BOARD -
CONTROL BOARD
42 00326030-02 CABLE MOTOR OUTPUT BELT 1
235 00326032-01 CABLE MOTOR INPUT BELT 1
250 00326031-02 CABLE: MOTOR CENTER BELT1 SPARE PART
325 00326026-02 CABLE VALVE STOPPER 1 SPARE PART
434 00326061-01 CABLE STEPPING M. LIFTING TABLE
1 - CON
435 00326063-01 CABLE POWER SUPPLY - STEPPING
MOTOR CON
436 00326064-01 CABLE SIGNALS LIFTING T. 1 -
CONV. BOARD
437 00331297-01 CABLE: I/O CONVEYOR BELTS
Cable trees
Page 17 / 18 18.11.2021
Pos. Item no. Description Part marking
30-POLE
438 00326067-01 CABLE POWER SUPPLY - HALF
BRIDGE
452 00326070-01 CABLE: POWER UNIT CONVERSION
PCB
Spare Part
453 00326068-01 CABLE:OUTPUTCLAMP FIELD-
CONVERSION PCB
Spare Part
454 00326069-01 CABLE:INPUT CLAMP FIELD-
CONVERSION BOARD
Spare Part
455 00329283-01 CABLE: CONTROL UNIT
CONVERSION PCB
SPARE
42 00326030-02 CABLE MOTOR OUTPUT BELT 1
235 00326032-01 CABLE MOTOR INPUT BELT 1
250 00326031-02 CABLE: MOTOR CENTER BELT1 SPARE PART
325 00326026-02 CABLE VALVE STOPPER 1 SPARE PART
431 00326061-01 CABLE STEPPING M. LIFTING TABLE
1 - CON
432 00326063-01 CABLE POWER SUPPLY - STEPPING
MOTOR CON
433 00326064-01 CABLE SIGNALS LIFTING T. 1 -
CONV. BOARD
434 00331297-01 CABLE: I/O CONVEYOR BELTS
30-POLE
435 00326067-01 CABLE POWER SUPPLY - HALF
BRIDGE
448 00326070-01 CABLE: POWER UNIT CONVERSION
PCB
Spare Part
449 00326068-01 CABLE:OUTPUTCLAMP FIELD-
CONVERSION PCB
Spare Part
450 00326069-01 CABLE:INPUT CLAMP FIELD-
CONVERSION BOARD
Spare Part
451 00329283-01 CABLE: CONTROL UNIT
CONVERSION PCB
SPARE
101 00306767-01 CABLE:CONVERSION BOARD
109 00306768-02 CABLE:CONVERSION BOARD
138 00310091-02 CABLE: CONVERSION BOARD
ADHESIVE APPLICATION HEAD
139 00310092-03 CABLE:CONVERSION BOARD-GLUE
HEA D
10 00333560-01 CABLE: GLUE STRIPPING ROLL
22 00316917-01 CABLE DECODER SYSTEM - READ
