1004-004 USING YOUR EXPLODED ILLUSTRA TION This Exploded Illustration shows the information about the parts of T ape Feeder for GXH-3 Series and is made for Parts Ordering. Y ou must not replace a part with a new one acc…

1004-004
立体分解図のご利用にあたって
この立体分解図は、
GXH-3
シリーズ用テープフィーダの部品構成についての情報
を記載したもので、部品のご注文のために作成されたものです。
この立体分解図の情報のみによって部品交換作業を行わないでください。
1.
立体分解図の見方
部品のイラストレーションには、各部品を検索するための番号がつけられ
ています。この番号が、部品リストの最左欄の
Key No.
です。
部品リストの
Q'ty
欄に記載されている数量は、原則として装置
1
台中の
個数を示します。ただし、組立品の構成部品については、その組立品
1
組
中の個数を示します。
2.
部品のご注文について
ご注文については、部品構成上単品部品で供給できない場合がございます。
ご注文の際には、次の事項をお知らせください:
モデル型式
装置製造番号
(Serial No.)
イラスト番号
(Fig. No.)
Key No.
部品番号
(P
ART No.)
部品名
(P
ART NAME)
必要個数
(Q'ty)
(
例 )
3.
その他
この立体分解図の内容は、予告なく変更することがあります。
この立体分解図の無断転載を禁じます。
'' NOTE ''
は、安全とは直接関係しない注意書きを示すのに、用いられます。
この立体分解図に記載されている部品のうち、外国為替及び外国貿易管理法に
定める戦略物資に該当するものについては、輸出する場合、同法に基づく輸出
許可が必要です。
GT-18080B
モデル型式
Model Type
GT18080 7890
装置製造番号
Serial No.
Key No.12
Key No.
6301265834
部品番号
PART No.
個数
Q'ty
1
イラスト番号
Fig. No.
Fig. W-1
部品名
PART NAME
ROLLER
PREFACE-1

1004-004
USING YOUR EXPLODED ILLUSTRATION
This Exploded Illustration shows the information about the parts of Tape Feeder for
GXH-3 Series and is made for Parts Ordering.
You must not replace a part with a new one according to only the information of this
Exploded Illustration.
1. Inquiring
For identification of each part, numbers are placed on illustration pages. These
numbers (Key No.) again appear in the far left column of the part table joined up
with the illustration.
The number shown in the Q’
ty column of the part table represents the quantity of
certain part used in the equipment. In case of unit assembly, however
, the number
represents the quantity of certain part contained in single unit.
2. Parts Ordering
For ordering parts, some parts might not be supplied as a single item, due to the
constitution of such parts.
When ordering parts, be sure to inform us of the following details:
Model
Type
Serial No.
Fig. No.
Key No.
P
AR
T No.
P
ART NAME
Quantity
[Example]
3. Miscellaneous
This Exploded Illustration is subject to change without prior notice.
All rights reserved. No part of this work covered by the copyrights hereon may be
reproduced or copied without written permission of the publisher.
'' NOTE '' is used to show the notice that is not directly related to safety.
Some of the parts shown in the Exploded Illustration could fall into the scope of your
government’s regulations on strategic products. In that case, anybody who intend to
export the product should acquire due authorization.
GT-18080B
Model Type
GT18080 7890
Serial No.
Key No.12
Key No.
6301265834
PART No.
Q'ty
1
Fig. No.
Fig. W-1
PART NAME
ROLLER
PREFACE-2
0712-002
CONT-1
目 次
CONTENTS
Fig. W
テープフィーダ
TAPE FEEDER
GT-18080B, 18081B, 18082B, 18083B GT-18080B, 18081B, 18082B, 18083B
Fig.
W-1
フレーム部
Frame Section
Fig.
W-2
テープ駆動部
Tape Driving Section
Fig.
W-3
カバーテープ巻取り部
Cover Tape W
inding Section
Fig. W-4
サプレッサ部
Suppressor Section
Fig. W-5
操作パネル部
Operation Panel Section
Fig.
W-6
モーターコントロール基板
Motor Control PCB
Fig. G
テープフィーダ
GT-12161B TAPE FEEDER GT-12161B
Fig. G-1
フレーム部
Frame Section
Fig. G-2
テープ駆動部
Tape Driving Section
Fig. G-3
カバーテープ巻取り部
Cover Tape W
inding Section
Fig. G-4
サプレッサ部
Suppressor Section
Fig. G-5
操作パネル部
Operation Panel Section
Fig. G-6
モーターコントロール基板
Motor Control PCB
Fig. P
テープフィーダ
GT-24321B T
APE FEEDER GT-24321B
Fig. P-1
フレーム部
Frame Section
Fig. P-2
テープ駆動部
T
ape Driving Section
Fig. P-3
カバーテープ巻取り部
Cover
Tape W
inding Section
Fig. P-4
サプレッサ部
Suppressor Section
Fig. P-5
操作パネル部
Operation Panel Section
Fig. P-6
モーターコントロール基板
Motor Control PCB
Fig. Q
テープフィーダ
GT-44561B TAPE FEEDER GT-44561B
Fig. Q-1
フレーム部
Frame Section
Fig. Q-2
テープ駆動部
T
ape Driving Section
Fig. Q-3
カバーテープ巻取り部
Cover
Tape W
inding Section
Fig. Q-4
サプレッサ部
Suppressor Section
Fig. Q-5
操作パネル部
Operation Panel Section
Fig. Q-6
モーターコントロール基板
Motor Control PCB
Fig.
T
テープフィーダ
GT-72001B TAPE FEEDER GT
-72001B
Fig. T-1
フレーム部
Frame Section
Fig.
T-2
テープ駆動部
Tape Driving Section
Fig.
T-3
カバーテープ巻取り部
Cover Tape W
inding Section
Fig. T-4
サプレッサ部
Suppressor Section
Fig. T-5
操作パネル部
Operation Panel Section
Fig.
T-6
モーターコントロール基板
Motor Control PCB
