1004-004 Key No. P AR T No. P AR T NAME Q’ty REMARKS New Code NOTE Q-5 Q-5 list-1 404 6301627045 P .C.B,MOUNT 1 877Q--1 10-504 4B1 1 1602 417 09262007 ASSY_GRIP 1 877Q--010-017 09262007 418 6301556888 COVER(GRIP) 1 877Q-…
1004-003
テープフィーダ
TAPE FEEDER
GT-44561B
GT-44561B
Fig. Q-5
操作パネル部
Operation Panel Section
431
417
436
404
418
445
See Fig.Q-1
Key No.1
Q-5 illust-1
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
Q-5
Q-5 list-1
404 6301627045 P.C.B,MOUNT 1 877Q--110-504 4B111602
417 09262007 ASSY_GRIP 1 877Q--010-017 09262007
418 6301556888 COVER(GRIP) 1 877Q--010-018 211AB843
431 221AB004 BOLT_HEX-SCT 2 M4X22 877Q--010-031 221AB004
436 4111151507 SCR TPG PAN 3X12 2 877Q--010-036 221N0005
445 08040003 NAME PLATE,INDEX 1 877Q--010-045 08040003
GT-44561B
0712-002
テープフィーダ
TAPE FEEDER
GT-44561B
GT-44561B
Fig. Q-6
モーターコントロール基板
Motor Control PCB
535
See Fig.Q-3
Key No.257
508
See Fig.Q-2
Key No.149
See Fig.Q-3
Key No.221
See Fig.Q-5
Key No.404
526
526
526
501
505
502
503
See Fig.Q-1
Key No.2
VIEW "A"
A
Q-6 illust-1
