1004-004 10 10 3 1 See Fig.P-1 Key No.2 7 8 9 6 4 See Fig.P-1 Key No.47 See Fig.P-5 Key No.445 16 18 2 17 1 1 15 14 20 19 21 継ぎ 目検出ユニット JOINT DETECTION UNIT DS-24320 DS-24320 Fig. PD-1 24,32mm 幅テープフィーダ用 For 24,32mm T ape…
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
1 6301544595 FRAME 1 804GD-110-001 210B4142
2 6301308302 ASSY,COVER 1 804GD-110-002 011A0007
3 6301308319 COVER(D) 1 804GD-110-003 211A9111
4 6301308296 PLATE 1 804GD-110-004 211D9941
6 6301289021 SENSOR,PHOTO 1 B01 804GD-110-006 23G10090
7 4110392604 SCR PAN 2X6 2 804GD-110-007 221E0483
8 4111412509 WASHER SPR 2 2 804GD-110-008 221H0276
9 4111413605 WASHER V 2X5X0.3 2 804GD-110-009 221H0307
10 4110335700 SCR FLT 2.5X6 4 804GD-110-010 221D0261
11 221AA096 BOLT,HEX-SCT 2 M4X20 804GD-110-011 221AA096
14 0804000C NAME PLATE,INDEX 1 804GD-110-014 0804000C
15 0804000B NAME PLATE,INDEX 1 804GD-110-015 0804000B
16 6301614670 MACHINE SCREW 2 M3X6 PAN+SW+W SUS
804GD-110-016 221D0195
21 6301578453 GUIDE 1 804GD-110-021 212A2467
DS-12160
GD-1
GD-1 list-1
1004-004
10
10
3
1
See Fig.P-1
Key No.2
7
8
9
6
4
See Fig.P-1
Key No.47
See Fig.P-5
Key No.445
16
18
2
17
11
15
14
20
19
21
継ぎ
目検出ユニット
JOINT DETECTION UNIT
DS-24320 DS-24320
Fig. PD-1
24,32mm
幅テープフィーダ用
For 24,32mm Tape Feeder
PD-1 illust-1
1004-004
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
1 6301544595 FRAME 1 804PD-110-001 210B4142
2 6301335346 ASSY,COVER 1 804PD-110-002 011A0013
3 6301308319 COVER(D) 1 804PD-110-003 211A9111
4 6301335230 PLATE 1 804PD-110-004 211DA221
6 6301289021 SENSOR,PHOTO 1 B01 804PD-110-006 23G10090
7 4110392604 SCR PAN 2X6 2 804PD-110-007 221E0483
8 4111412509 WASHER SPR 2 2 804PD-110-008 221H0276
9 4111413605 WASHER V 2X5X0.3 2 804PD-110-009 221H0307
10 4110335700 SCR FLT 2.5X6 4 804PD-110-010 221D0261
11 221AA096 BOLT,HEX-SCT 2 M4X20 804PD-110-011 221AA096
14 0804000C NAME PLATE,INDEX 1 804PD-110-014 0804000C
15 0804000B NAME PLATE,INDEX 1 804PD-110-015 0804000B
16 6301614670 MACHINE SCREW 1 M3X6 PAN+SW+W SUS
804PD-110-016 221D0195
17 6301335223 PLATE 1 804PD-110-017 211DA220
18 4110022600 SCR FLT 3X6 2 804PD-110-018 221D0216
19 6301366753 PLATE 1 804PD-110-019 211DA550
20 4111134708 SCR FLT 4X10 2 804PD-110-020 221D0219
21 6301578477 GUIDE 1 804PD-110-021 212A2468
DS-24320
PD-1
PD-1 list-1
