34 Mechanical Drawings 157376 Issue 1 1 Under Screen Cleaner (300 LG) GA 5 4 3 2 1 A B C C B A 123 45 67 8 9 10 11 12 13 6 7 8 9 10 11 12 13 D E F G H I D E F G H I PROJECTION DRAWN APPROVED DATE C COPYRIGHT DO NO T SCAL…

100%1 / 108
Mechanical Drawings 33
157375 Issue 11 Under Screen Cleaner (400 LG) GA
54321
A
B
CC
B
A
12345
67
8
9 10
11 12
13
6
7
8
9
10 11
12
13
D
E
F
G
H
I
D
E
F
G
H
I
PROJECTION
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
2000
BOM NUMBER
A
A
A
A
A
ITEM PART NO. DESCRIPTION QTY.
1
107269 TUBING CLIP,SINGLE DIA.4.0 2
2
107499 Y-UNION 1
3
109239 SUNX PHOTO SENSOR PM T53 1
4
145740 CLP EXT D1400/20 1
5
145754 SPRING PLATE 2
6
145756 SPRING CLAMP BLOCK 2
7
145761 LH END PLATE 1
8
145770 KNURLED WHEEL 2
9
145771 WHEEL SHAFT 1
10
145772 OPTO DISC 1
11
145865 OLDHAM COUPLING 19 DIA 1
12
145866 TORQUE DISC 19 DIA 1
13
145867 COUPLING 1
14
145873 ROLLER CLUTCH 1
15
145874 DRIVE SPINDLE 1
16
145883 SPRING HOUSING 1
17
145886 BEARING DGBB 61804-2Z 1
18
145887 SPRING COMPRESSION 1
19
145894 PAPER SPINDLE 2
20
157113 VACUUM ELBOW 2
21
157114 CASSETTE TRAY 1
22
157116 RH END PLATE 1
23
157122 END CAP 2
24
157373 USC PAPER FEED MOTOR 1
25
157379 SQUEEGEE ASSEMBLY 1
26
157381 U.S.C. BODY 1
27
157442 BLANKING PLUG 1
28
157533 USC PAPER ROLL (400mm) 1
29
157551 ST CONNECTOR (KQSO4-M6) 1
30
157770 USC PAPER ROLL 1
31
158904 SHAFT^SPRUNG^USC^^ 1
32
158905 WASHER^^USC^^ 1
33
165670 VALVE^SOLVENT_DISPENSE^UCS 1
34
165675 CYLINDER ASSY^20 BORE^4 STROKE 2
35
165824 BRACKET^VALVE MOUNT^USC 1
36
700002 SCREW M3X6 PAN.HD SLTD MC ST.ST 1
37
B0018 BEARING DGBB 608-2RS 1
38
B0021 BEARING DGBB 626 ZZ 2
39
G1434 CLP EXT D1400/8 1
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:2
A HAMLIN
USC (400 LG)
21-Apr-99
157375 157323
SH 1
OF 1
A
0
LATEST
ISSUE
No. DATE DCR INITIAL
11 20-Jan-03 27701 PB
ITEMS 22,34 & 36
REMOVED FOR CLARITY
17
8
9
21
22
23
25
26
27
28
29
30
33
35
20
2 5 6
34
3
10
19
SECTION A-A
SCALE 1:1
11 12
13
14
15
37
39
24
4
16
17
18
38
32
36
31
SECTION A-A
SCALE 1:1
34 Mechanical Drawings
157376 Issue 11 Under Screen Cleaner (300 LG) GA
54321
A
B
CC
B
A
12345
67
8
9 10
11 12
13
6
7
8
9
10 11
12
13
D
E
F
G
H
I
D
E
F
G
H
I
PROJECTION
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
2000
BOM NUMBER
A
A
B
B
ITEM PART NO. DESCRIPTION QTY.
1
107269 TUBING CLIP,SINGLE DIA.4.0 2
2
107499 Y-UNION 1
3
109239 SUNX PHOTO SENSOR PM T53 1
4
145740 CLP EXT D1400/20 1
5
145754 SPRING PLATE 2
6
145756 SPRING CLAMP BLOCK 2
7
145761 LH END PLATE 1
8
145770 KNURLED WHEEL 2
9
145771 WHEEL SHAFT 1
10
145772 OPTO DISC 1
11
145865 OLDHAM COUPLING 19 DIA 1
12
145866 TORQUE DISC 19 DIA 1
13
145867 COUPLING 1
14
145873 ROLLER CLUTCH 1
15
145874 DRIVE SPINDLE 1
16
145883 SPRING HOUSING 1
17
145886 BEARING DGBB 61804-2Z 1
18
145887 SPRING COMPRESSION 1
19
145894 PAPER SPINDLE 2
20
157113 VACUUM ELBOW 2
21
157114 CASSETTE TRAY 1
22
157116 RH END PLATE 1
23
157122 END CAP 2
24
157373 USC PAPER FEED MOTOR 1
25
157378 SQUEEGEE ASSEMBLY 1
26
157386 U.S.C. BODY 1
27
157442 BLANKING PLUG 2
28
157532 USC PAPER ROLL (300mm) 1
29
157551 ST CONNECTOR (KQSO4-M6) 1
30
157770 USC PAPER ROLL 1
31
158904 SHAFT^SPRUNG^USC^^ 1
32
158905 WASHER^^USC^^ 1
33
165670 VALVE^SOLVENT_DISPENSE^UCS 1
34
165675 CYLINDER ASSY^20 BORE^4 STROKE 2
35
165824 BRACKET^VALVE MOUNT^USC 1
36
700002 SCREW M3X6 PAN.HD SLTD MC ST.ST 1
37
700730 PIN 2DIA X 20LG SPR(GROVERLOCK) 1
38
B0018 BEARING DGBB 608-2RS 1
39
B0021 BEARING DGBB 626 ZZ 2
40
G1434 CLP EXT D1400/8 1
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:2
A HAMLIN
USC (300LG)
20-Apr-99
157376 157324
SH 1
OF 1
A
0
LATEST
ISSUE
No. DATE DCR INITIAL
11 20-Jan-03 27701 PB
ITEMS 22,34 & 36
REMOVED FOR CLARITY
17
8 9
21
22
23 25
26
27
28
29
30
33
35
20
2 5 6
34
3
10
19
PART SECTION A-A
SCALE 1:1
11 12 13
14
15
3840
37
24
PART SECTION B-B
SCALE 1:1
4
16
17
18
39
31
32
36
Mechanical Drawings 35
157509 Issue 5 USC Drive Carriage Assembly GA
54321
A
B
CC
B
A
12345
67
8
9 10
11 12
13
6
7
8
9
10 11
12
13
D
E
F
G
H
I
D
E
F
G
H
I
PROJECTION
DRAWN
APPROVED
DATE
C
COPYRIGHT
DO NOT SCALE
SCALE
TITLE
DRAWING NUMBER
2000
BOM NUMBER
Z
Z
ITEM PART NO. DESCRIPTION QTY.
1
107265 ELBOW F/F 2
2
107332 ARMATURE PLATE 2
3
107443 RARE EARTH POT TYPE MAGNET 2
4
107660 VANE 1
5
114245 WASHER 2
6
119664 FILLER CAP 1
7
119667 WASHER SEALING 1
8
129217 MAGNET HOLDER, LH 1
9
129504 MAGNET HOLDER, RH 1
10
129505 SOLVENT TANK 1
11
140535 SEALING WASHER 1
12
156581 BEARING BLOCK 2
13
156583 PLATE, USC CHAIN FRONT 1
14
156924 DRIVE UNIT ASSEMBLY 1
15
157281 INTERFACE BRACKET 1
16
157319 MANIFOLD SPACER 1
17
165677 BRACKET^L/H^SOLVENT TANK 1
18
165678 BRACKET^R/H^SOLVENT TANK 1
19
181161 BOM^LIQUID LEVEL SENSOR^SOLVENT TANK^USC 1
20
700102 SCREW M3X10 CAP HD ST.ST 2
21
700109 SCREW M4X8 CAP HD ST.ST 4
22
700114 SCREW M4X30 CAP HD ST.ST 2
23
700115 SCREW M5X12 CAP HD ST.ST 4
24
700131 SCREW M5X8 CAP HD ST.ST 2
25
700312 SCREW M3X8 BUTT.HD ST.ST 2
26
700415 SCREW M3X16 CSK.SLTD.M/C ST.ST 2
27
700603 WASHER M5 PLAIN FORM A ST.ST 4
28
700609 WASHER M3 CRINKLE BE/CU 2
29
700611 WASHER M5 CRINKLE BE/CU 4
30
700656 6BA T2 WASHER S/S 4
31
G0332 FLEXO 123008 SPRING 2
THIS DRAWING AND THE COPYRIGHT
IN IT, IS THE PROPERTY OF
DEK PRINTING MACHINES LIMITED
IT MAY NOT BE COPIED, REPRODUCED,
PUBLISHED OR DISCLOSED IN WHOLE
OR IN PART WITHOUT OUR WRITTEN
CONSENT.
1:2
A HAMLIN
DRIVE CARRIAGE ASSEMBLY
25-June-02
157509
157538
SH 1
OF 1
A
0
LATEST
ISSUE
No. DATE DCR INITIAL
05 25-June-02 27478 PB
PART SECTION Z-Z
SCALE 1:1
1
2
3
1
5
2
6
1
7
1
9
1
10
1
11
1
14
1
16
1
17
1
18
1
31
1
31
1
3
1
8
1
22
1
22
1
20
2
30
2
26
2
21
2
24
2
21
2
12
2
19
1
29
4
4
1
30
2
25
2
28
2
