14.3.3.4 Pressure.dat
This file is created in run mode and records squeegee pressures during the print stroke.
14.3.3.5 Ptest.dat
This file is created when calibrating the squeegee reference height with pressure hardware en-
abled. The file records the amount of steps the squeegee is driven down with the pressure
achieved.
14.3.3.6 Screen.dat
This file is created when cycle alignment system is running in diagnostics and records positional
deviations of the stencil fiducial.
14 SCREEN ALIGNMENT MODULE
14.3 TEST CYCLES
190 TECHNICAL REFERENCE MANUAL Vol 1 E By DEK 04/2019
15 BOARD STOP
15.1 INTRODUCTION
TECHNICAL REFERENCE MANUAL Vol 1 E By DEK 04/2019 191
15
BOARD STOP
15.1 INTRODUCTION
There are two types of Board Stop:
●
Camera Mounted Board Stop
●
Remote Mounted Board Stop
The camera mounted option is used to stop small, comparatively lightweight products in the correct
print position where they are clamped. The remote board stop is mounted on the rising table and
provides a more robust unit for larger, heavier products.
