2.11 Lubricating the ST9 Air Valve Push Pin
Arrow marks in the illustration indicate lubrication points.
C7SM3020b
Valve push pin overview
Do not apply grease
on the air blow hole.
Apply grease
(39)
(39)
AFC grease
Monthly
T011b
Lubrication points
Schedule
Types of lubricant
39
Valve push pin
Part 3 Chapter 2 Lubrication
Edition 2.9 3-2-16 CP-7 series Mechanical Reference
2.12 Lubricating the Parts Reject Unit
Arrow marks in the illustration indicate lubrication points.
Black arrows indicate points where a grease gun is required.
(41)
(41)
(40)
C7SM3107a
(42)
Connect the hose to the special
grease nozzle (DGPJ0550), and
then insert the nozzle tip into the
LM guide grease port.
Special grease
nozzle
Hose
Valve push pin overview
Do not apply grease
on the air blow hole.
Apply grease
AFC grease
AFC grease
T018E
Lubrication points
Schedule
Types of lubricant
41
Every 3 months
42
Cam follower
Every 3 months
LM rail
Monthly
AFC grease
40
Valve push pin
Part 3 Chapter 2 Lubrication
Edition 2.9 3-2-17 CP-7 series Mechanical Reference
2.13 Lubricating the Pallet Table
Arrow marks in the illustration indicate lubrication points.
C7SM3023b
(43)
(43)
(43)
(43)
(43)
(43)
(43)
(43)
(43)
(43)
(43)
(43)
(43)
(43)
(43)
(44)
(44)
(44)
(44)
<CP-733E, CP-743ME>
<CP-743E>
(44)
(44)
(43)
(43)
(43)
(43)
(43)
(43)
(43)
(43)
(44)
(44)
(43)
AFC grease
Every 3 months
Every 3 months
AFC grease
Pallet clamp surface
Clamp pin
T012a
Lubrication points
Schedule
Types of lubricant
43
44
Part 3 Chapter 2 Lubrication
Edition 2.9 3-2-18 CP-7 series Mechanical Reference
