Part 2

Basic Operation

1. Changing the Conveyor Width

Point

Conveyor width adjustments must be performed jointly at the in-conveyor, XY-table,

and out-conveyor. The conveyors should be adjusted to a width which permits smooth

panel clamping and conveyance through the machine.

Procedure

CAUTION

Before performing conveyor width adjustment, check the

back-up pin positions on the XY-table, verifying that there

will be no interference between the back-up pins and the

adjustable rail.

1. Execute the necessary commands to link the XY-table to the in and out-conveyors.

At the touch panel’s main screen, select the following commands: [Conveyor] -

[Conveyor Width] - [Change Width], then press the START button.

2. Turn the handle on the out-conveyor to adjust the conveyor width until the panel

can be conveyed smoothly. First increase the conveyor width then reduce it to

between 0.5~1.0 mm wider than the panel width.

3. Lower the XY-table.

4. Run a test panel through the machine, verifying that it is conveyed smoothly and

that panel clamping is correctly performed.

W+(0.5~1.0)

(mm)

C7SM2001a

Panel

C7SM2007

Handle

Part 2 Chapter 1 Changing the Conveyor Width

Edition 2.6 2-1-1 CP-7 series Mechanical Reference
