2. Lubrication
Precautions During Lubrication
• Prior to beginning any lubrication, turn the main breaker off.
• Apply an appropriate amount of lubricant. If too much lubricant is applied, it
may splatter and drop on panels inside the machine. Special care should be taken
to keep the camera lens clean, as a soiled lens results in poor part inspection
results. Use a lens cleaner to keep the lens clean.
Types of Lubricant
The lubricants which are used have the following characteristics.
Note: Do not mix grease types.
Daphne Eponex No. 2
Multemp SRL
AFC Grease
Lithium grease by Idemitsu suited to mid/low speed parts.
Lithium grease by Kyodo Oils suited to high/mid/low speed parts.
Multemp LRL3
Lithium grease by Kyodo Oils suited to mid/low speed parts.
High grade synthetic oil based on grease by THK suited to
high speed parts.
SHC 630
Turbine oil +
NASKALUBE
This MOBIL, PAO based oil is used on gears and axis components.
A Fuji special blend containing additives, used for the purpose of
enhancing durability.
Characteristics
Table-lub-b
Type
Daphne
Super Multi Oil 32
High grade synthetic based oil by Idemitsu used as a multi-purpose
lubricating oil applicable to a wide range of parts that require
lubrication.
Part 3 Chapter 2 Lubrication
Edition 2.9 3-2-1 CP-7 series Mechanical Reference
Grease Gun Kit
A grease gun kits with which grease supply for almost all Fuji equipment can be
performed is available from Fuji. The grease gun kit comes with all the nozzles required
to apply grease to the various grease fitting formats. To obtain the grease gun kit, please
contact your Fuji agent.
Included Parts
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
GRSKIT02E
Name: Fuji grease gun kit
Code: AWPJ8201
FUJI Grease gun kit contents:
No. Name Code
Format
Quantity
1
2
3
4
5
6
7
8
9
10
11
12
Box Sheet
Sheet
Sheet
Mushroom Nipple
Grease Gun
Syringe
Rubber Hose
Air Hose
Nozzle
Nozzle
Nozzle
Nozzle
EA506J
PE light (Sponge)
Polyurethane
KH-120 (with HSP-1)
SJ-S30S
SPK-3C
TU0604B-310 mm
L-type
N-type
N-1-type
P-type
1
1
1
1
1
1
1
2
1
1
1
1
13
14
Nozzle
Tube
U-type
PTFE tube 2x3-150 mm
1
1
15
16
Connector
Connector Nipple
PN-1/8-PT1/8-BS
TS6-01
1
1
17 Sleeve 40-13
PJ
WPJ1271
WPJ1281
WPJ1261
K1153F
S2184A
H5456T
T2063H
N5004A
N5005A
N5006A
N5007A
N5008A
T2061E
K5030T
S2176B
S3084A 1
GRSKIT01E
Part 3 Chapter 2 Lubrication
Edition 2.9 3-2-2 CP-7 series Mechanical Reference
The CP-7 series requires the following grease nozzles, which are not included in the
standard grease gun kit.
Lubrication Instructions
Illustrations and tables are used to indicate important information about keeping the
machine properly lubricated.
■ Type and Schedule for Lubrication
Within these illustrations, symbols are used to indicate the location, type and schedule
for lubrication.
The lubrication schedules are based on eight hours of operation per day, five days per
week (40 hours) and 20 days per month (160 hours). However, if the machines are being
operated in two or three shifts per day, the lubrication schedules should be used as
follows.
Daily: Eight hours from when the machine is turned on, after every
eight hour shift, or after one day's operation.
Weekly: After 40 hours of operation, whether the machine is being used
in two or three shifts, or after one week's operation.
Monthly: After 160 hours of operation, whether the machine is being used
in two or three shifts, or after one month's operation.
Every 3 months: After 480 hours of operation, whether the machine is being used
in two or three shifts, or after three month's operation.
Every 6 months: After 960 hours of operation, whether the machine is being used
in two or three shifts, or after six month's operation.
Annually: After 1920 hours of operation, whether the machine is being
used in two or three shifts, or after a year of operation.
ST3 nozzle clutch
LM block nozzle
C7SM3115
DGPJ054✽
Parts reject unit
LM block nozzle
DGPJ055✽
ADGPJ818✽
NZ-axis LM block nozzle
