KKS_YG12_PL - 第31页
6 7 Sensor Conveyor Unit KKS-091 1 2 5 9 2 8 10 7 3 4 8 7 6 6 5 4 2 3 7 8 8 10 7 7 10 9 1 1 1 1 1 2 1 1 1 1 1 1 1 7 10 L>R R>L No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date 1 KHM-M654C-01 SENS…
5
7
Main Conveyor 2
Conveyor Unit
KKS-1102
36
40
40
5
41
40
4
20
39
34
35
16
35
28
35
1
31
38
31
2
32
21
42
34
3
12
19
18
21
42
37
17
35
41
20
14
13
14
32
40
40
36
5
31
38
31
8
30
43
11
11
7
6
26
31
31
35
41
20
38
22
40
4
9
9
7
43
30
8
11
11
26
6
22
40
22
20
41
17
5
8
31
38
35
31
8
5
10
44
45
34
28
15
40
22
23
23
R>L
16
34
39
10
L>R
24
46
46
26
26
27
27
29
29
25
33
39
24
25
26
26
27
27
29
29
33
39
43
47
43
47
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHY-M9113-00 PULLEY 1,MOTOR 1
2 KHY-M9117-00 SPLINE 1 1
3 KHY-M9118-00 BRACKET F,COLLAR 1
4
KHY-M9121-00 FRAME,CONVEYOR 2 1250
KHY-M9121-10 FRAME,CONVEYOR 2 1460
5
KHY-M9123-00 GUIDE 1 4 1250
KHY-M9123-10 GUIDE 1 1 1460
6
KHY-M9124-00 PLATE 1,GUIDE 2 1250
KHY-M9124-10 PLATE 1,GUIDE 1 1460
7
KHY-M9125-00 PLATE 2,GUIDE 2 1250
KHY-M9125-10 PLATE 2,GUIDE 2 1460
8
KHY-M9126-00 GUIDE 1-1 4 1250
KHY-M9126-10 GUIDE 1-1 2 1460
9
KHY-M9129-00 BELT 1,CONVEYOR 2 1250
KHY-M9129-10 BELT 1,CONVEYOR 1 1460
10
KHY-M912A-01 BRKT.,SENSOR 1 OK MG40138-2010/5/10
KHY-M912A-00 BRKT.,SENSOR 1
11
KHY-M9135-00 PLATE,EDGE 2 14 OK MGX0072-2011/1/12
KHY-M9135-00 PLATE,EDGE 2 16
12 KHY-M9157-00 SHAFT,MOTOR 1
13 KG2-M9105-00 PULLEY 1,SPLINE 1
14 KG2-M9108-11 COLLAR,CONVEYOR 2
15 KHY-M9111-00 BRKT.1,SPLINE 1
16 KGA-M9113-00 GUIDE 1,END 2
17 KGA-M9114-00 GUIDE 2,END 2
18 KGK-M9170-00 DC MOTOR ASSY. 1
19 KGT-M9193-00 NUT PLATE 4
20 KGY-M9140-A0 PULLEY,CONV. ASSY 4
21 KH2-M9105-11 PULLEY,MOTOR:P30-3GT 2
22 KV1-M9140-A0 PULLEY CONV.ASSY. 4
23 KV7-M9140-A0 PULLEY CONV.ASSY. 2
24 KHY-M911G-00 COVER,TERMINAL 2
25 KHY-M911Y-00 PLATE,TERMINAL 2
26 90563-03J100 SPACER BOLT 8
27 90563-03J400 SPACER BOLT 8
28 90990-28J076 WASHER 2
29 91312-03005 BOLT HEX.SOCKET HEAD 8 M3X5
30 91312-03006 BOLT HEX.SOCKET HEAD 16 M3X6
31 91312-03008 BOLT HEX.SOCKET HEAD 46 M3X8
32 91312-03010 BOLT HEX.SOCKET HEAD 8 M3X10
33 91312-04008 BOLT HEX.SOCKET HEAD 8 M4X8
34 91312-04010 BOLT HEX.SOCKET HEAD 8 M4X10
35 91312-04012 BOLT HEX.SOCKET HEAD 10 M4X12
36 91312-05020 BOLT HEX.SOCKET HEAD 2 M5X20
37 91317-04055 BOLT HEX.SOCKET HEAD 4 M4X55
38 92902-03200 WASHER PLAIN 16
39 92902-04200 WASHER PLAIN 11
40 92902-05200 WASHER PLAIN 8
41 92902-05600 WASHER PLAIN 4
42 92A08-04303 SET SCREW 4
43 98702-03005 SCREW FLAT HEAD 32
44 KH2-M9121-00 BEARING 1
45 91312-04006 BOLT HEX.SOCKET HEAD 2 M4X6
46 KJJ-M4554-00 TERMINAL BOARD ASSY. 2
47 KHY-M9135-10 PLATE,EDGE 3 2 MGX0072-2011/1/12
6
7
Sensor
Conveyor Unit
KKS-0911
2
5
9
2
8
10
7
3
4
8
7
6
6
5
4
2
3
7
8
8
10
7
7
10
9
1
1
1
1
1
2
1
1
1
1
1
1
1
7
10
L>R
R>L
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KHM-M654C-01 SENSOR,FIBER 2 1
2 KHW-M9157-00 HOLDER,SENSOR 2
3 KHY-M652J-00 SENSOR,ENT ASSY 1
4 KHY-M652K-00 SENSOR,WAIT ASSY 1
5 KHY-M652L-00 SENSOR,POS.1 ASSY 1
6 KHY-M652M-00 SENSOR,EXIT ASSY 1
7 91312-03004 BOLT HEX.SOCKET HEAD 6 M3X4
8 91312-03008 BOLT HEX.SOCKET HEAD 4 M3X8
9 92A08-03303 SET SCREW M3X3 1
10 97602-03310 SCREW,PAN HEAD W/W 4
1
8
Multi Camera & Light Assy
Camera
KKS-1011
1
40
OLD
39
2
3
26
35
31
36
31
33
34
30
29
27
28
32
32
4
4
12
17
18
23
12
12
12
10
10
5
11
7
21
22
6
20
8
37
38
24
25
19
14
15
16
9
20
13
24
25
No. Part No. Part Name Q'ty Remarks Compati. Revision No.-date
1 KKS-M73C0-50 C+L W50-H267-U/D 1
2
KKS-M7560-01 SIDE LIGHT ASSY 1 NG MFY0059-2009/12/15
KKS-M7560-00 SIDE LIGHT ASSY 1
3 KJJ-M755S-A1 M.LIGHT BRD.SIDE SET 1
4
KJJ-M755S-02 M.LIGHT BOARD SET 1 NG MF20031-2009/3/18
KJJ-M755S-01 M.LIGHT BOARD SET 1
5 KJJ-M7512-01 COVER,GLASS 1
6 KJJ-M7513-00 DIFFUSER,COAX 1
7 KJJ-M7516-01 COVER,LIGHT UNIT 1
8 KJJ-M7522-01 PLATE,COAX. 1
9 KJJ-M7525-00 SPACER 4
10 KJJ-M7526-01 PLATE,GLASS 4
11 KJJ-M7542-00 AR SHEET 1
12
Delete MFY0059-2009/12/15
KJJ-M7545-01 RUBBER,LIGHT 1 6
13
Delete MFY0059-2009/12/15
KJJ-M7546-00 RUBBER,LIGHT 2 2
14 KJJ-M66N2-00 HNS,M.LIGHT COAX. 1
15 KJJ-M66N9-01 HNS,M.LIGHT SUB CX. 1
16 KJJ-M66NA-01 HNS,M.LIGHT MAIN 1
17 KJJ-M7570-00 SPACER 12
18 98902-03004 SCREW BINDING HEAD 12 M3X4
19 98502-03004 SCREW PAN HEAD 4 M3X5
20 98502-03006 SCREW PAN HEAD 6 M3X6
21 98902-03006 SCREW BINDING HEAD 2 M3X6
22 98902-03010 SCREW BINDING HEAD 4 M3X10
23 KJJ-M7518-01 FRAME,MAIN LIGHT 1
24 90563-03J250 SPACER BOLT 4
25 90563-03J300 SPACER BOLT 2
26 KJJ-M7511-00 FRAME,SIDE LIGHT 1
27 KJJ-M7514-00 DIFFUSER,SIDE LIGHT 1
28 KJJ-M7515-01 COVER,SIDE LIGHT 1
29 KJJ-M7523-A1 CYLINDER ASSY 1
30 KJJ-M66N8-01 HNS,M.LIGHT SIDE 1
31 $SSF4-M5-A-P JOINT 2
32 90K41-000240 SEAL,DON'T TOUCH 2
33
98502-03003 SCREW PAN HEAD 8 M3X3 OK MFY0098-2009/12/22
98507-03003 SCREW PAN HEAD 8 M3X3
34
98502-04006 SCREW PAN HEAD 4 M4X5 OK MFY0098-2009/12/22
98507-04005 SCREW PAN HEAD 4 M4X5
35 91312-04010 BOLT HEX.SOCKET HEAD 2 M4X10
36
91312-04020 BOLT HEX.SOCKET HEAD 2 M4X20 OK MFY0098-2009/12/22
91317-04020 BOLT HEX.SOCKET HEAD 2 M4X20
37 91312-06020 BOLT HEX.SOCKET HEAD 2 M6X20
38 92902-06200 WASHER PLAIN 2
39 KHW-M8582-40 VALVE 1
40 KKJ-M73C0-00 C+L W50-H267-NON 1 Non Side Light ASSY
