7-12
 输入&输出 (INPUT/OUTPUT)
PIN NO. DEF. DESCRIPTION
1 CANH
CAN 通信信号
2 CANL
连接其它NODE的CAN通信信号
3 /IO-RES
RESET 信号
FROM CAN MASTER
CN2/CN
3
6 +12V
A/D用 +12V 电源
FROM CAN MASTER
1 24VP
OUTPUT PORT用 DC+24V 电
源
输入READY SW后供电
2 24V
INPUT PORT用 DC+24V 电源 生成BOARD电源DC+5V
CN4
3/4 24G
DC+24V 电源 GROUND
-
3 IN1.0 PCB INPUT SENSOR
4 IN1.1 PCB WAIT SENSOR
9 IN1.2
DUMP CONVEYOR FULL
INPUT
10 IN1.3
DUMP CONVEYOR BUSY
INPUT
15 IN1.4 PCB PLACE SENSOR
16 IN1.5 PLACE STOPPER UP SENSOR
21 IN1.6
PLACE STOPPER DOWN
SENSOR
CN14
22 IN1.7 SECOND PLACE SENSOR
24PIN CONNECTOR(在3段C/V时不
使用WAIT STOPPER UP/DOWN传
感器)
3 IN2.0 BUT UP SENSOR
4 IN2.1 BUT DOWN SENSOR
9 IN2.2 HOLE FIXER RIGHT SENSOR
10 IN2.3 HOLE FIXER LEFT SENSOR
15 IN2.4 RESERVED INPUT PORT
16 IN2.5 RESERVED INPUT PORT
21 IN2.6 RESERVED INPUT PORT
CN15
22 IN2.7 RESERVED INPUT PORT
24PIN CONNECTOR
3 IN3.0 PCB OUT SENSOR
4 IN3.1 RESERVED INPUT PORT
9 IN3.2 RESERVED INPUT PORT
10 IN3.3
ANC1 SHUTTER CLOSE
SENSOR
15 IN3.4
ANC1 SHUTTER OPEN
SENSOR
16 IN3.5 RESERVED INPUT PORT
21 IN3.6 RESERVED INPUT PORT
CN16
22 IN3.7 RESERVED INPUT PORT
24PIN CONNECTOR(在3段C/V时不
使用OUT STOPPER UP/DOWN传
感器)
3 IN4.0 FRONT EMERGENCY INPUT CN17
4 IN4.1 FRONT DOOR INPUT
24PIN CONNECTOR
7-13
PIN NO. DEF. DESCRIPTION
9 IN4.2
FFEEDER CHANGE SW.
INPUT
10 IN4.3 READY SW. INPUT
15 IN4.4 START SW. INPUT
16 IN4.5 STOP SW. INPUT
21 IN4.6 RESET SW. INPUT
22 IN4.7 POWER ON INPUT
3 IN5.0 REAR EMERGENCY INPUT
4 IN5.1 REAR DOOR INPUT
9 IN5.2
RFEEDER CHANGE SW.
INPUT
10 IN5.3
FRONT OPERATION STATUS
INPUT
15 IN5.4
REAR OPERATION STATUS
INPUT
16 IN5.5
MAIN AIR SENSOR
21 IN5.6 REAR SO
CN18
22 IN5.7 FRONT SO
24PIN CONNECTOR
3 OUT1.0 RESERVED OUTPUT
4 OUT1.1 PLACE STOPPER SOL PORT
9 OUT1.2 BUT SOL
10 OUT1.3 HOLE FIXER SOL
15 OUT1.4 EDGE PUSHER SOL
16 OUT1.5 RESERVED OUTPUT PORT
21 OUT1.6 ANC1 SHUTTER SOL
CN5
22 OUT1.7 RESERVED OUTPUT PORT
24PIN CONNECTOR
3 OUT2.0 RESERVED OUTPUT PORT
4 OUT2.1 READY SW. LAMP OUT
9 OUT2.2 START SW. LAMP OUT
10 OUT2.3 STOP SW. LAMP OUT
15 OUT2.4
RFEEDER CHANGE SW. LAMP
OUT
16 OUT2.5
FFEEDER CHANGE SW. LAMP
OUT
21 OUT2.6 RESET SW. LAMP OUT
CN6
22 OUT2.7 READY RELAY OUTPUT
24PIN CONNECTOR
1 OUT3.0 RED LAMP OUTPUT
2 OUT3.1 BLUE LAMP OUTPUT
3 OUT3.2 GREEN LAMP OUTPUT
CN7
4 OUT3.3 RESERVED OUTPUT PORT
6PIN CONNECTOR
CN8 1/3 OUT3.4 FRONT BELT CONTROL 6PIN CONNECTOR
7-14
PIN NO. DEF. DESCRIPTION
2/4 OUT3.5 REAR BELT CONTROL
1/3 OUT3.6
前段设备 I/F OUT
CN9
2/4 OUT3.7
后段设备 I/F OUT
6PIN CONNECTOR
3 IN6.0
FRONT FEEDER UNLOCK
SENSOR
CN19
4 IN6.1
REAR FEEDER UNLOCK
SENSOR
6PIN CONNECTOR
3 IN6.2
INLINE PREVISOUS
AVAILABLE INPUT
CN20
4 IN6.3 INLINE NEXT BUSY INPUT
6PIN CONNECTOR
3 IN7.0 FRONT AREA SENSOR
CN21
4 IN7.1 RESERVED INPUT PORT
6PIN CONNECTOR
3 IN7.2 REAR AREA SENSOR
CN22
4 IN7.3 RESERVED INPUT PORT
6PIN CONNECTOR
3 IN7.4 FRONT DOCKING SENSOR 1
CN23
4 IN7.5 FRONT DOCKING SENSOR 2
6PIN CONNECTOR
3 IN7.6 REAR DOCKING SENSOR 1
CN24
4 IN7.7 REAR DOCKING SENSOR 2
6PIN CONNECTOR
CN25 2 AN0
RESERVED ANALOG INPUT
PORT
6PIN CONNECTOR
1 TXD SERIAL TRANSMISSION LINE
2 RXD SERIAL RECEIVE LINE
3 IN6.4 FRONT_KEYPAD_USED
4 IN6.6 FRONT_KEYPAD_EMG
5 +12V JOGBOX +12V POWER
CN26
6 GND GROUND
FROM FRONT JOGBOX
CONNECTOR
1 TXD SERIAL TRANSMISSION LINE
2 RXD SERIAL RECEIVE LINE
3 IN6.5 REAR_KEYPAD_USED
4 IN6.7 REAR_KEYPAD_EMG
5 +12V
JOGBOX用 +12V 电源
CN27
6 GND GROUND
FROM REAR JOGBOX
CONNECTOR
1 TXD SERIAL TRANSMISSION LINE
2 RXD SERIAL RECEIVE LINE
CN28
3 GND GROUND
TO MVME3100 BOARD
3 OUT4.0 FRONT DOCKING CART SOL1
CN10
4 OUT4.1 FRONT DOCKING CART SOL2
6PIN CONNECTOR
3 OUT4.2 REAR DOCKING CART SOL1
CN11
4 OUT4.3 REAR DOCKING CART SOL2
6PIN CONNECTOR
CN12 3 OUT4.4 RESERVED OUTPUT PORT 6PIN CONNECTOR
