P a r t L i s t C a r r i e r A s s ' y 3 1 Page S A M S U N G T E C H W I N NO. PARTNO. PARTNAME Q'TY TYPE REMARK 1 J9058070A AIRDISTRIBUTORMODULE 1 J9058063A 1-A J7158013A MANIFOLD 1 1-B J9058071A AIR…
C
arrier As s y
30 Page
S A MS UNG TE CHW IN
1-F
1-A
1
1-E
1-D
1-B
1-C
2
1-G
1-H
P art L is t
C
arrier As s 'y
31 Page
S A MS UNG TE CHW IN
NO. PARTNO. PARTNAME Q'TY TYPE REMARK
1
J9058070A AIRDISTRIBUTORMODULE 1
J9058063A
1-A
J7158013A MANIFOLD 1
1-B
J9058071A AIRTANKASS'Y 6
1-C
GAUGE 1
1-D
VALVE 6
1-E
VALVE 1
1-F
J9058072A FILTERASS'Y 6
J6708009A FILTER 6
1-G
SPEEDCON' 2
1-H
REGULETOR 1
2
J6713022B COILTUBE(POLYURETHANE) 6 J6713022B
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
1
3
2
E
ntry C onveyor As s 'y
32 Page
