F o o t A s s ' y 7 Page S A M S U N G T E C H W I N 2 1-A 1 1-C 1-B 1-D
P art L is t
A
ir As s 'y
6 Page
S A MS UNG TE CHW IN
NO. PARTNO. PARTNAME Q'TY TYPE REMARK
1 J1300620 SPEEDCONTROLLER
1
2 J1301700 CHECKUNION
8
3 J6711166A DOUBLEUNION
2
4 J6711168A UNIONYFITTING
1
5 J7500010A COUPLER
1
J7500010A
6 J9058084A VACUUMPUMPMODULE
1
J9058084A
7 J1300183 SOCKETHEADSCREW
4
M4*10
8 J1300438 SOCKETHEADSCREW
2
M4*8
9 J6707003A VACUUMPUMP
1
10 J6711139A STRAIGHTFITTING
1
11 J6711140A STRAIGHTFITTING
1
12 J6711169A ELBOWFITTING
2
13 J6712008A PLUG
3
14 J7058001B PUMPBRACKET
1
J7058001B
15 J9061897A AIRSOLV/VCABLEASS'Y J9061897A
16 J6702021A SOLENOIDVALVE
1
17 J6713016A AIRTUBE(POLYURETHANE) U2-4-4*2.5(BLACK)
18 J6713017A AIRTUBE(POLYURETHANE) U2-4-6*4(BLACK)
19 J6713018A AIRTUBE(POLYURETHANE) U2-4-8*5(BLACK)
20 J6713034A AIRTUBE(POLYYRETHANE) U2-4-6*4(YELLOW)
21 J6713035A AIRTUBE(POLYYRETHANE) U2-4-4*2.5(BLUE)
22 J6713036A AIRTUBE(POLYYRETHANE) U2-4-4*2.5(YELLOW)
23 J1300210 SPRINGWASHER
4
M5
24 J1300438 SOCKETHEADSCREW
8
M4*8
25 J1300446 SOCKETHEADCAPSCREW
2
M8*10
26 J1301334 SOCKETHEADSCREW
4
M5*35
27
F
oot A s s 'y
7 Page
S A MS UNG TE CHW IN
2
1-A
1
1-C
1-B
1-D
P art L is t
F
oot A s s 'y
8 Page
S A MS UNG TE CHW IN
NO. PARTNO. PARTNAME Q'TY TYPE REMARK
1
FOOTASS'Y
4
1-A
J7051009C BOLT-FOOT
4
J7051009B
1-B
J7051010D HOUSING-FOOT
4
J7051010B
1-C J2100018
NUT-FOOT
4
0131-611026
1-D J2101561
CUSHION-FOOT
4
0131-611025-P1
2 J6109001A
SWIVELCASTER
4
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
