Installation Manual Station Software Version 408.01 4.3.1.4 Setup page "Date and Time" ┌────┤ Date and Time ├────┐ │┌───────────────────────┐│ ││ Time 0:00:00 ││ ││ Date 10-Apr-1997 ││ │└───────────────────────…
Installation Manual, Station Software Version 408.01 Edition 03/2006
4.3.1.2 Terminating the BIOS Setup
From the main menu, use the ESC key to call the exit menu:
┌───────┤ Setup Exit ├─────────┐
│ │
│ Do you wish to save │
│ the changes to CMOS? │
│ │
│ ╔══════╗ ┌──────┐ ┌──────┐ │
│ ║ SAVE ║ │ EXIT │ │RETURN│ │
│ ╚══════╝ └──────┘ └──────┘ │
│ │
│ Press [F1] key for help │
└──────────────────────────────┘
Choose "SAVE" to save the set parameters.
Choose "EXIT" to exit Setup. The old parameters remain set.
Choose "RETURN" to return to the main menu of the Setup.
More information about using the Setup and the parameters on the various Setup pages can be
found in the following sections.
4.3.1.3 Setup page "System Security"
┌───────────┤ System Security ├──────────────┐
│ │
│ ┌Device Security───────────┐ ╔══════╗ │
│ │[ ] Floppy Disk Read Only │ ║ OK ║ │
│ │[ ] Hard Disk Read Only │ ╚══════╝ │
│ └──────────────────────────┘ ┌──────┐ │
│ │Cancel│ │
│ ┌Password──────────────────┐ └──────┘ │
│ │[ ] Enter Setup │ │
│ │[ ] System Boot │ │
│ └──────────────────────────┘ │
│ Press [F1] key for help │
└────────────────────────────────────────────┘
37 of 104
Installation Manual Station Software Version 408.01
4.3.1.4 Setup page "Date and Time"
┌────┤ Date and Time ├────┐
│┌───────────────────────┐│
││ Time 0:00:00 ││
││ Date 10-Apr-1997 ││
│└───────────────────────┘│
│┌───────────────────────┐│
││ ╔══════════╗ ││
││ ║ OK ║ ││
││ ╚══════════╝ ││
│└───────────────────────┘│
│ Press [F1] key for help │
└─────────────────────────┘
The values can be modified using the cursor keys or by deleting the entry using the backspace key.
4.3.1.5 Setup page "AT Hard Disk"
The parameters of all IDE hard disks installed in the system are entered in this setup page.
┌──────────────────────────────┤ AT Hard Disk ├──────────────────────────────┐
│ ╔═══════════════╗ ┌──────┐ ┌──────┐ │
│ ║AUTO All Drives║ │ OK │ │Cancel│ Drive Wait Time: 8 sec │
│ ╚═══════════════╝ └──────┘ └──────┘ │
│ ┌─Primary IDE Controller──────────────────────────────────────────────────┐│
│ │ Trans Block 32- Fast││
│ │ Auto Type Cyl Heads SPT Precomp L-Zone Size Mode Mode Bit PI0 ││
│ │Master: [√] USR1 3648 255 63 None ???? ???? LBA [ ] [ ] [ ] ││
│ │ ││
│ │Slave: [ ] NONE 0 0 0 0 0 0 Normal [ ] [ ] [ ] ││
│ └─────────────────────────────────────────────────────────────────────────┘│
│ ┌─Secondary IDE Controller────────────────────────────────────────────────┐│
│ │ Trans Block 32- Fast││
│ │ Auto Type Cyl Heads SPT Precomp L-Zone Size Mode Mode Bit PI0 ││
│ │Master: [ ] NONE 0 0 0 0 0 0 Normal [ ] [ ] [ ] ││
│ │ ││
│ │Slave: [ ] NONE 0 0 0 0 0 0 Normal [ ] [ ] [ ] ││
│ └─────────────────────────────────────────────────────────────────────────┘│
│ Press [F1] key for help │
└────────────────────────────────────────────────────────────────────────────┘
Parameters for a 30-GB IDE hard disk
38 of 104
Installation Manual, Station Software Version 408.01 Edition 03/2006
Primary IDE Controller
The following parameters must be defined for the first IDE channel.
Auto If this option is activated, the BIOS will attempt to detect the parameters
of the hard disk and to set them up optimally on startup.
Type The hard disk type is always USR1
Cyl Number of cylinders of the hard disk
Heads Number of heads of the hard disk
SPT Number of sectors per track
Precomp Write precompensation
L-Zone Landing zone
Size The size of the hard disk in MB will be calculated automatically by the
BIOS based on the parameters and cannot be set.
Trans Mode Transfer mode of hard disk
Normal
For hard disks larger than 504 MB, Normal Mode has to be used under
RMOS.
Important:
None of the options Block Mode, 32 bit or Fast PIO may be activated.
Drive Wait Time
This is the time the BIOS waits for a response from an IDE hard disk during startup.
39 of 104
