Installation Manual Station Software Version 408.01
• You are now requested to insert the floppy MCRMOS HS50 Disk -1/2- into the drive.
• After both floppies have been installed, the message "Installation finished" appears.
The M54 operating system has been completely installed.
Now remove the floppy from the drive and switch the machine off and then on again.
4.3.4 Changing the network addresses
To change the internet addresses, you must
• Switch the machine off
• Insert installation floppy #1 and switch the machine on
• Press the key 'A' in the first menu
• The menu offers you the choice of setting the Internet addresses or the port IDs.
[X] EXIT M ENU [H] SET INTER NET AD DR ESS
[S] SET PO RT ID
PRESS KE Y TO CO NTINU E [H,S,X]?
• If 'H' is selected, the file '\ETC\HOSTS' appears in the DOS editor.
The Internet addresses and system names valid for this station must be entered.
Note:
The ALIAS names "autlr", "autsr" and "localhost" must not be changed, as these names are used and
required by the software.
Example of hosts:
#******************************************************************************
#
# File : C:\ETC\HOSTS
#
# Author/Date : T. Noetzold 16-Aug-1995
#
# Abstract : Konfigurationsdatei fuer TCP/IP
#
# Inskript: : AUT 5 BSM 13 $Author:: ake/mme $
# $Date:: 10 Sep 1996 23:41:16$
# $Revision:: 3.0 $
#
# Usage : Durch TCP/IP-Software
#
#******************************************************************************
# Copyright (C) 1992-1996 by Siemens AG. All rights reserved
#******************************************************************************
#
52 of 104
Installation Manual, Station Software Version 408.01 Edition 03/2006
# Internet Official List Of Aliases # Comment
# Address Host Name
#
127.255 loop
172.22.231.84 local localhost # my IP address!
172.22.231.82 autsr traceserver # station computer
220.9.200.1 autgem # gem computer
# --- end of host file ---
• A&D EA 1 has a globally unique Class B internet address. This official Class B Internet address is
139.10 (.x.y). All SIPLACE-LAN communication partners operate within this address range. We will make
the correct settings for you. (This information is also contained in the machine documents). Should you
have any queries, contact our Service department.
• If 'S' is selected, the file '\ETC\SERVICES' appears in the DOS editor.
• If 'X' is selected, the menu is exited and the DOS prompt appears.
Remove the floppy from the drive.
• To start the SIPLACE system, switch the machine off and then on again.
4.3.5 Troubleshooting
• If the installation program terminates prematurely due to an error, remove the floppy from the drive
and switch the machine off.
• Insert floppy #1 into the drive and switch the machine on again.
• Try installing the operating system again.
Note
If the software can still not be installed on the second attempt, contact your Service center.
53 of 104
Installation Manual Station Software Version 408.01
1 Kurzbeschreibung
Die Installationsanleitung dient als Arbeitsanweisung für die Installation der SIPLACE
Stationssoftware SR 408.01.
Sie enthält Informationen über den Lieferumfang und die Voraussetzungen zur erfolgreichen
Installation.
Die Software SR 408 wurde speziell zum Betrieb der Automatentypen entwickelt:
• SIPLACE CS
• SIPLACE CF
• SIPLACE S23
• SIPLACE F5 HM
Hinweis: SIPLACE S23 nicht von der Stationssoftware 408 unterstützt
Die SIPLACE S23 wird derzeit nicht von der Stationssoftware 408 unterstützt wird aber in
Kürze freigegeben werden.
Mehr dazu erfahren Sie bei der SIPLACE Hotline: Hotline.SIPLACE@mchrm.siemens.de.
