Overview of the Modules C&P20, C&P20 A and C&P20 M 2.6.1 Differentiation of the C&P20 He ad Variants 28 Service Manual SIPLACE SX1/SX2/DX1/DX2 FS02 2.6.1 2 . 6 . 1 D if f e r e n t ia t io n o f t h e C &…
Overview of the Modules
2.4.4 Width Adjustment CPP
Service Manual SIPLACE SX1/SX2/DX1/DX2 FS02 27
2.5
2.5 CPP
CPP
2.6
2.6 C&P20, C&P20 A and C&P20 M
C&P20, C&P20 A and C&P20 M
CPP
CPP with camera SST29 [03070108-xx]
CPP without camera [03053528-xx]
1. Intermediate distributor 1 and 2 (ID1, ID2)
2. Star motor (integrated in head housing)
3. DP axis (as direct drive)
4. Pressure control valve
5. Component camera (behind the intermediate distrib-
utor, standard: SST29)
6. Single core solution (SCS) – DP drive control
7. Holding circuit supply, integrated venturi nozzles and
valve assembly (valve terminal)
8. Z axis with return cylinder
9. Component sensor in the pick and place position (on
the underside)
C&P20 A
1. Star motor
2. Pressure control valve
3. DP drives (20 x)
4. Star with 20 nozzles
5. Component Camera
6. Intermediate distributor board
Overview of the Modules
C&P20, C&P20 A and C&P20 M 2.6.1 Differentiation of the C&P20 Head Variants
28 Service Manual SIPLACE SX1/SX2/DX1/DX2 FS02
2.6.1
2.6.1 Differentiation of the C&P20 Head Variants
Differentiation of the C&P20 Head Variants
Differenc es between CP 20/A/M
The C&P20A differs from the C&P20 in the following issues:
▪ New E/D transformer
▪ Improved linear guide rails at the segments
▪ Driver bearing
▪ Modified Z-axis (also used in C&P20 later on)
▪ Hoses
▪ FHE components
The C&P20M differs from the C&P20A in the following issue:
▪ Incremental encoder of the star motor
NOTICE
C&P20, C&P20A, C&P20M
The instructions apply in principle to all C&P20, C&P20A and C&P20M heads.
Any differences will be explicitly indicated.
► The different heads can be recognized according to the labeled stickers.
Overview of the Modules
2.6.1 Differentiation of the C&P20 Head Variants Twin and Twin HF
Service Manual SIPLACE SX1/SX2/DX1/DX2 FS02 29
2.7
2.7 Twin and Twin HF
Twin and Twin HF
2.8
2.8 DLM
DLM
Twin
The TwinHead consists of two Pick&Place modules.
1. Module 1
2. Module 2, rotated by 180° compared to module 1.
3. Main board on relevant module
4. D axis
5. Linear motor Z axis
6. Z axis incremental measurement system
7. Camera lens hood Twin
X-Series S, SX4/DX4, X-Series, HF: [03001846-xx]
SX1/SX2/DX1/DX2 [03079524-xx]
1. Intermediate distributor, digital (under the cover)
2. Star motor
3. Z axis motor
4. Stepping motor
5. Component camera
