GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 105 of 152 Page 105 of 152
RollHeightHardware
70
The current selection of the Paste Roll Height
Monitor (PRHM) hardware
U1
0=NotFitted
1=Fitted
RollHeightMonitor
72
The current status of the PRHM option
U1
0=Disabled
1=Enabled
ConsumableAction
73
The current setting for the action to perform
when a consumable is low
U1
0=Warn
1=Pause
2=Suspend
VacuumHoldTime
74
The time the vacuum is applied to the tolling
before the quality of the vacuum seal is checked
(s)
F4
2DiMovementTuning
75
The settling time used in 2D Inspection per site
(ms)
U2
CleanerVacuum
76
The current status of the cleaner vacuum option
U1
0=Standard
1=Vacuum
PasteTrails
77
The current status of the paste trails option
U1
0=Disabled
1=Enabled
TransportWaitMode
78
The current setting for the transport wait mode
U1
0=Standard
1=Hold At Print
ClampType
80
The current selection for the board clamp type
U1
0=Board Clamps
1=Snuggers
2=Foil Less Clamps
3=Over The Top
Snuggers
ToolingMonitoring
81
The rate (in boards) that the Tooling Deviation
Monitoring option is used
U2
0 – 200. 0 = disabled
FiducialMonitoring
83
The current selection for the Fiducial
Monitoring option
U1
0=Smart
1=Normal
FiducialSearch
84
The current selection for the Fiducial Search
option
U1
0=Disabled
1=Custom
RemoteBoardStopHard
ware
85
The current selection for the Remote Board Stop
hardware
U1
0=NotFitted
1=Fitted
BoardStopXOffset
86
The current camera board stop X offset
F4
CameraIdlePosition
88
The current selection for the Camera Idle
Position option
U1
0=Home
1=Behind Rail
UnloadBoardStart
89
The current selection for the Unload Board Start
option
U1
0=Transport
1=Separation
MaintenanceMonitorin
g
95
The current state of the Maintenance Monitoring
option
U1
0=Disabled
1=Enabled
MachineLocation
96
Free format entry to describe the location of the
machine
A20
AutoRailWidth
97
The current selection for the Automatic Rail
Width option
U1
0=Disabled
1=Enabled
ProductDirectory
98
The path to the local folder where the product
files are stored
A260
DataFileLocation
99
The path to the local folder where data and log
files are stored
A260
DownlineBoardStop
101
The current selection of the HTC Downline
Board Stop option
U1
0=Never
1=Always
2=Auto
AdjustPageType
102
The current selection for the Adjust page option
U1
0 = Standard
1 = Reduced
Sublimits
103
The current selection of the Adjust Page sub-
limits option
U1
0 = Disabled
1 = Enabled
FrontRToLSpeed
104
The speed of the front rail belt when running
from right to left
U2
FrontLToRSpeed
105
The speed of the front rail belt when running
from left to right
U2
GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 106 of 152 Page 106 of 152
RearLToRSpeed
106
The speed of the rear rail belt when running
from right to left
U2
RearRToLSpeed
107
The speed of the rear rail belt when running
from left to right
U2
AltFrontRToLSpeed
108
The alternate speed of the front rail belt when
running from right to left
U2
AltFrontLToRSpeed
109
The alternate speed of the front rail belt when
running from left to right
U2
AltRearLToRSpeed
110
The alternate speed of the rear rail belt when
running from left to right
U2
AltRearRToLSpeed
111
The alternate speed of the rear rail belt when
running from right to left
U2
GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 107 of 152 Page 107 of 152
7.3 Status Variables
The status variables are defined in the table below:
Name
SVID
Limits
Monitor
Description
Type
Value Range
GemAlarmsEnabled
1001
No
List of alarms that are enabled.
List
A list of “n” ALID’s.
GemAlarmsSet
1002
No
List of alarms that are set.
List
A list of “n” ALID’s.
See chapter 6 for ALID’s.
GemAlarmState
1003
No
State of last alarm transition.
U1
0 = OFF
1 = ON
clock
1004
No
Host view of equipment time.
(centisecond precision)
A12/A16
Yymmddhhmmss
Yyyymmddhhmmsscc
GemControlState
1005
No
Current GEM Control State.
U1
1 = Equipment Off-Line
2 = Attempt On-Line
3 = Host Off-Line
4 = Local
5 = Remote
process_state
1006
No
Current Equipment Process State.
U1
0 = Equipment Ready
1 = Equipment Waiting
2 = Equipment Running
3 = Equipment Setup
4 = Equipment Down
5 = Equipment Recovery
6 = Equipment Maintenance
GemEventsEnabled
1007
No
List of collection events enabled.
List
A list of “n” CEID’s.
See chapter 7.
humidity
1008
Yes
Current humidity in print area.
F4
0-100 %
model_number
1009
No
Model number.
A6
String
previous_command
1010
No
Last command received from operator
or host.
A
See appendix A.
GemPreviousControlState
1011
No
Control state prior to last transition.
U1
See GemControlState.
last_process_state
1012
No
Process state before last transition.
U1
See process_state.
GemPreviousCeid
1013
No
CEID of last collection event to occur.
U4
See chapter 7.
Reserved
1014
No
software_version
1015
No
Software revision 6 char ASCII.
A6
See chapter 4. (SOFTREV)
temperature
1016
Yes
Current temperature in the print area.
F4
0 -100 (Celsius)
current_time
1017
No
Host view of equipment time.
(1 second precision)
A12/A16
Yymmddhhmmss
Yyyymmddhhmmsscc
system_mode
1018
No
The current machine mode.
U1
0 = Step
1 = Auto
2 = Single
3 = No Print
PPExecName
1019
No
Name of current process program.
A68
batch_count
1020
Yes
Number of Boards printed.
U4
0-99999
Reserved
1021
No
time_last_print
1022
No
Time of the last print.
A12/
A16
Yymmddhhmmss/
Yyyymmddhhmmsscc
spc_data_mode
1023
No
Reporting mode of the SPC.
U1
0 = Serial
1 = Disk
2 = Invalid
3 = None
