GEM Manual for DEK Printers Event Messages

Issue 1.1 March 20th, 2014 Page 135 of 152 Page 135 of 152

31442

Paste kneaded after host command.

31443

Paste conditioned after host command.

31458

Proflow pressure adjusted.

40010

Comms - Adjust front print speed.

40011

Comms - Adjust rear print speed.

40041

Request to start

40325

Host Command Start Failed

40326

Host Command Stop Failed

40327

Host Command Pause Failed

40328

Host Command Erase Log Failed

40329

Host Command Erase Batch Failed

40330

Host Command Erase Session Failed

40331

Host Command Rename Product Failed

40332

Host Command Adjust Product Failed

40333

Host Command Clean 1 Failed

40334

Host Command Clean 2 Failed

40335

Host Command Paste Failed

40336

Host Command PP-Select Failed

40337

Host Command Change Screen Failed

40338

Host Command Knead Paste Failed

40376

Host Command Save Product Failed

9.12 Limits Monitoring Events

EVENT - CEID

DESCRIPTION

31000-31200

Status Variables see section 5.5

32000-33000

Discrete Variables see section 5.5

GEM Manual for DEK Printers Event Messages

Issue 1.1 March 20th, 2014 Page 136 of 152 Page 136 of 152

9.13 Suggested Event Reports

EVENT - CEID

DESCRIPTION

DVID DATA

31277

Board printed.

2008 Front print pressure

2009 Rear print pressure

2010 Print speed

2016 Squeegee

2011 Separation speed

31316

Inspection cycle

complete.

2012 Stretch error

2013 X alignment accuracy

2014 Y alignment accuracy

2015 Theta alignment

32010

(example of a

report for Limits

monitoring)

print_speed crosses

a limit.

2010 print_speed

2027 LimitVariable

2028 EventLimit

2029 TransitionType

40177

(example of a

report for

Traceability

reporting)

Data is available

2033 Traceability Data

9.14 SIMULTANEOUS EVENTS (TIME)

Reference SEMI E30-95 section 4.10.4 Paragraph 4, assignment of centisecond values.

Simultaneous Events may occur on the equipment. The nature of the control software is such that

these events are collected serially as the programme executes. Each collection event that occurs and

is enabled is added to a queue for transmission. This queue is serviced once every program cycle.

Another event will not be transmitted until the previous event has been acknowledged by the Host.

This will always take longer than 10 ms. The program cycle in any case is always greater than 10

ms.

Take the case that the Host creates some reports containing the “clock” variable. The Host then

attaches two of these reports to "Event A" and "Event B". If Event A is detected first then the value

of “clock(A)” would be read as the report is compiled and transmitted. Subsequently the value of

“clock(B)” would be read as the report is compiled and transmitted. Thus, they will always be seen

by the host to occur at different times. The centisecond clock precision is provided by the operating

system.

9.15 MODIFIED PARAMETERS

Procedure to configure event report mentioned section 5.2.1.

Using event reports, Host machine can get notification for modified parameters on change.

 Define event report using S2F33 command. A report includes one or more machine

variables. To get list of modified parameters, include Modified Parameters (DVID 2088) in

report definition.

GEM Manual for DEK Printers Event Messages

Issue 1.1 March 20th, 2014 Page 137 of 152 Page 137 of 152

 Link event report using S2F35 command. The Host links one or more reports to a collection

event CEID using S2F35. Link defined report with following CEIDs.

31345

Configuration Parameter modified

31346

Product Data modified

31347

Adjust Parameter modified

 Enable event report using S2F37 command. Include all above-mentioned CEIDs to get

modified parameter list at all events.

After performing above steps from Host, When any parameters changed on instrument and

instrument is connected through GEM, Instrument will send report data to host.

<S6F11 W

<L[3/1]

<U4[1/1] 1>

<U4[1/1] 31345> /* CEID */

<L[1/1]

<L[2/1]

<U4[1/1] 35> /* RPID */

<L[1/1]

<L[6/1]

<L[4/1]

<U4[1/1] 5> /* Parameter Id */

<A[12/1] "SCREEN IMAGE"> /* Parameter Name */

<A[4/1] "EDGE"> /* Old value */

<A[6/1] "CENTRE"> /* Modified value */

<L[4/1]

<U4[1/1] 280>

<A[12/1] "SYSTEM PRESSURE">

<A[4/1] "3.8">

<A[6/1] "4.0">

… /* List of modified parameters */
