• Action of the Function Keys S STOP : Press to stop production after the curr ent board is completed. When the board has been completed the display returns to Page 100/000. After this command has been selected, “Stop Af…
FCP IV-3 Operation
Press this key to cycle the operation mode between the settings listed below.
The current operation mode is displayed in the machine status area.
PRODUCT : Normal production.
SIMULATE : Currently not supported.
IDLE : Does not pick up parts or carry out vision processing. Boards are
not fed out of the machine. The tape feeders feed parts from the
tape.
Note : The production mode (PRODUCT) is automatically set when the machine power is
turned on.
Chapter 3 Description of Commands
Selecting the Operation Mode
Part 3
3 – 17
MODE
Page
150 000
Version 5.0
• Action of the Function Keys
S STOP : Press to stop production after the current board
is completed. When the board has been
completed the display returns to Page 100/000.
After this command has been selected, “Stop
After Current Board” is displayed in the first
display area.
CANCEL : Press to cancel the previously selected
command. When [S STOP] is selected, the
function key changes to [CANCEL].
• Cycle Stop Button
Pressing the [CYCLE STOP] button causes the machine to stop
after the current sequence is finished. The display then returns
to Page 100/000.
• When an Alarm Occurs
Production is interrupted and the alarms are displayed in the
second display area. The display "Waiting for Reset SW"
displays. The system returns to Page 100/000 when the
[RESET] button is pressed.
• Function Key Menu
Chapter 3 Description of Commands
During Automatic Operation
Part 3
3 – 18
Page
170 000
S STOP
(CANCEL)
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
CHANGEOVER :In manual termination of Changeover mode, only the Passive
Cell is effective. When this key is pressed, the YES/NO
display will appear. When the [YES] key is pressed,
communication with LMS is established, and the machine will
clear off boards before starting changeover. When the [NO]
command key is pressed, the previous display will appear
again.
S STOP :Press to stop production after the current board is completed.
When the board has been completed the display returns to
Page 000/000. After this command has been selected, “Stop
After Current Board” is displayed in the first display area.
CANCEL :Press to cancel the [S STOP] command. This command
displays only after [S STOP] has been selected.
YES :Press to begin communication with LMS. The machine will
wait until any boards in the machine are cleared before
beginning changeover.
NO :Press to return to the previous function key display
• Cycle Stop Button
Pressing the [CYCLE STOP] button causes the machine to stop after the current
sequence is finished. The display then returns to Page 100/000.
• When an alarm occurs
Production is interrupted and the alarms are displayed in the second display area.
The buzzer sounds to indicate that the [RESET] button should be pressed. The
system returns to Page 100/000 when the [RESET] button is pressed.
When the operator presses [CHANGEOVER], changeover will begin.
• Function Key Menu
Chapter 3 Description of Commands
During Automatic Operation
(HELPS Only)
Part 3
3 – 19
Page
170 000
CHANGEOVER S STOP
NO
Version 5.0
FCP IV-3 Operation
YES
