• Action of the Function Keys UNLOAD PCB : Pr ess to unload the board. LOAD PCB : Pr ess to load a new board. LOAD PSTN : Press to move the table to the loading position. LIFTER ▲ / ▼ : Press to raise or lower the table.…
• Action of the Function Keys
AUTO :Press to carry out automatic operation.
CAM ORG POS Press to return cam axis to its origin position.
While this key remains pressed the cam will
move toward its origin position. Movement
stops when the cam returns to its origin.
Movement also stops if the key is released
before the cam reaches its origin.
The message "Return Cam to Zero" displays
in the second display area until the cam
reaches its origin. When the cam has
returned the message "Press START"
displays.
MARK EDITORFiducial Mark Recovery command.
Same as MARK EDITOR in page 100/000.
SEQ. NO. :Press to input the sequence number from
which operation is to start.
MODE :Press to select the operation mode.
RETURN :Press to return to Page 000/000.
• START Button
Pressing the [START] button once executes one program
sequence. Pressing it again carries out the next sequence, and
so on.
• Second Display Area
If start conditions are fulfiled, the message “Press START”
flashes. Otherwise an error displays.
• Function Key Menu
Chapter 3 Description of Commands
To Page 100/000
To Page 130/000
To Page 000/000
Step Operation
Part 3
3 – 20
STEP
Page
200 000
AUTO CAM ORG POS MARK EDITOR SEQ. NO. MODE RETURN
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
UNLOAD PCB:Press to unload the board.
LOAD PCB :Press to load a new board.
LOAD PSTN :Press to move the table to the loading
position.
LIFTER▲/▼ :Press to raise or lower the table. If this
command is pressed and the table is not in
the loading position, the display "Not at
Loading Position" appears. If the table does
not raise or lower in the time allowed, the
message "Lifter Timeout UP/DN" displays.
RETURN :Press to return to Page 000/000.
• Function Key Menu
Chapter 3 Description of Commands
To Page 310/000
To Page 320/000
To Page 330/000
To Page 000/000
Operating the Loader
Part 3
3 – 21
LOADER
Page
300 000
UNLOAD PCB LOAD PCB LOAD PSTN
LIFTER▼
(LIFTER▲)
RETURN
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
RETURN : Press to return to Page 300/000.
• START Button
Pressing the [START] button unloads the board from the XY
table if one is present. The display then returns to Page
300/000.
• Second Display Area
If start conditions are fulfiled, the message “Press START”
flashes. Otherwise an error displays. Refer to Part 6 for details
on error codes.
• Function Key Menu
Chapter 3 Description of Commands
To Page 300/000
Unloading Boards
Part 3
3 – 22
UNLOAD PCB
Page
310 000
RETURN
Version 5.0
FCP IV-3 Operation
