• Action of the Function Keys BLOCK : Press to set or clear the block skip setting. RETURN : Press to r eturn to Page 400/000. • First Display Area # Program name Prod. Sche. 1 PLACING_DATA 50 20 2 TEST A1 BOARD 0 3000 3…
FCP IV-3 Operation
Select this command to set the number of completed boards for the current
production program to zero.
Chapter 3 Description of Commands
Resetting the Number of
Completed Boards
Part 3
3 – 28
QTY. CLEAR
Version 5.0
Page
430 000
• Action of the Function Keys
BLOCK : Press to set or clear the block skip setting.
RETURN : Press to return to Page 400/000.
• First Display Area
# Program name Prod. Sche.
1 PLACING_DATA 50 20
2 TEST A1 BOARD 0 3000
3 TEST A2 OLD 130 1151
4 ***** * *
5 ***** * *
6 ***** * *
7 ***** * *
8 ***** * *
9 ***** * *
• Second Status Area
Ready
• Function Key Menu
Chapter 3 Description of Commands
To Page 441/000
To Page 400/000
Skipping Portions of a Program
Part 3
3 – 29
SKIP
Page
440 000
BLOCK RETURN
Version 5.0
FCP IV-3 Operation
FCP IV-3 Operation
• Action of the Function Keys
+ PAGE : Press to display the next page if a program
contains more than 40 blocks.
- PAGE : Press to display the previous page when a page
block greater than 40 is displayed.
RETURN : Press to return to Page 400/000.
• First Status Area
Block Skip
• Second Status Area
Block No.
• First Display Area
B1 P
B2 P
B3 P
B4 P
B5 S
Parts are placed on blocks 1 to 4. Block 5 is skipped. The
display depends on the program status.
P : Block for normal production
S : Block to be skipped
Blocks displayed in red have been set in MCS/2H to be
skipped.
• Input from Numerical Keypad
Input the number of the block to be skipped. If the block was
set to be produced, it will now be skipped, and vice versa. Note
that a block skip set in MCS/2H can only be cleared by
changing the program and retransmitting it to the machine.
• Function Key Menu
Chapter 3 Description of Commands
Skipping Blocks on a Board
Part 3
3 – 30
BLOCK
Page
441 000
+PAGE -PAGE RETURN
Version 5.0
To Page 440/000
