• Action of the Function Keys CHECK : Press to check the parts mounted on the device table for the current pr oduction program. OFFSET : Press to set an of fset for any device requiring it. For example, if a part is bein…

100%1 / 364
FCP IV-3 Operation
• Action of the Function Keys
+ PAGE : Press to display the next page if a program
contains more than 40 blocks.
- PAGE : Press to display the previous page when a page
block greater than 40 is displayed.
RETURN : Press to return to Page 400/000.
• First Status Area
Block Skip
• Second Status Area
Block No.
• First Display Area
B1 P
B2 P
B3 P
B4 P
B5 S
Parts are placed on blocks 1 to 4. Block 5 is skipped. The
display depends on the program status.
P : Block for normal production
S : Block to be skipped
Blocks displayed in red have been set in MCS/2H to be
skipped.
• Input from Numerical Keypad
Input the number of the block to be skipped. If the block was
set to be produced, it will now be skipped, and vice versa. Note
that a block skip set in MCS/2H can only be cleared by
changing the program and retransmitting it to the machine.
• Function Key Menu
Chapter 3 Description of Commands
Skipping Blocks on a Board
Part 3
3 – 30
BLOCK
Page
441 000
+PAGE -PAGE RETURN
Version 5.0
To Page 440/000
• Action of the Function Keys
CHECK : Press to check the parts mounted on the device
table for the current production program.
OFFSET : Press to set an offset for any device requiring it.
For example, if a part is being mispicked due to
slippage, it may require an offset to align the
center of the nozzle with the center of the part.
RETURN : Press to return to Page 400/000.
• First Status Area
DEVICE CHECK
• Function Key Menu
Chapter 3 Description of Commands
To Page 451/000
To Page 455/000
To Page 400/000
Working with Device Data
Part 3
3 – 31
DEVICE
Page
450 000
CHECK OFFSET RETURN
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
MODE 1 : Press to display 10 consecutive devices
regardless of whether each device is used or
not.
MODE 2 : Press to display only those devices that are to
be used.
MODE 3 : Press to display only those devices among the
devices being used that have a condition such
as "Un Set", "Parts E", "Pickup", or "Vision".
RETURN : Press to return to Page 450/000.
• First Status Area
DEVICE CHECK
• First Display Area
(a) (b) (c) (d)
D001 Un Set [0013] Device_comment_No_1
D002 Parts E [0008] Korewa_No2_Desu
D003 [0002] PCPR102TL
D004 [0000]
D005 Vision [0001] MSD2HD256
D006 Tape E [0005] Micro_Tr_Nol
D007 Next d [0000] Super_Mini_Tr
D008 [0002] Nihongonetute
D009 Pickup [0003] N3456Sd23
D010 [0015] Jaf
• Function Key Menu
Chapter 3 Description of Commands
To Page 451/100
To Page 451/200
To Page 451/300
To Page 450/000
Device Check Mode Selection
Part 3
3 – 32
CHECK
Page
451 000
MODE 1
MODE 2
MODE 3
RETURN
Version 5.0
