FCP IV -3 Operation • Action of the Function Keys TIMES : Enter any number fr om 1 to 9 inclusive to set the number of recovery attempts, and pr ess the [CR] key to execute the change. CHANGE : The machine automatically …
• Action of the Function Keys
RECOVERY :Press to select the recovery mode.
PASS :Press to select production or pass mode.
When the machine is operating in pass mode,
P MODE or PASS will be displayed in
cyan.TURNOVER : Press to select
turnover mode. This command is not
presently supported. Do not press this
function key.
TURNOVER: Press to select turnover mode. This
command is not presently supported. Do not
press this function key.
TABLE MODE :Press to change the device table operation
mode.
LINE :Press to select the communication mode with
the MCS 30 computer.
RETURN :Press to return to page 500/000.
• First Display Area
Turnover Mode
ST1.N 65 D 2 Er **** STATUS
ST2.N 64 D 2 Er **** P Mode Product
ST3.N 63 D 2 Er **** Recovery 3times
ST4.N 62 D 2 Er **** T Mode Joint
ST5.N 61 D 2 Er 0
ST6.N 60 D 2 Er 0
ST7.N 59 D 2 Er 0
Normal Turnover
• Function Key Menu
Chapter 3 Description of Commands
To Page 511/000
To Page 514/000
To Page 515/000
To Page 500/000
Changing the Machine Status
Part 3
3 – 41
STATUS
Page
510 000
RECOVERY PASS TURNOVER TABLE MODE LINE RETURN
Version 5.0
FCP IV-3 Operation
FCP IV-3 Operation
• Action of the Function Keys
TIMES :Enter any number from 1 to 9 inclusive to set the number of
recovery attempts, and press the [CR] key to execute the
change.
CHANGE :The machine automatically goes into auto-recovery mode when
the power is first turned on. The recovery mode changes every
time this key is pressed.
Auto-recovery:Recovery automatically takes place when an
error has occurred. If the set number of times
recovery is to take place is exceeded, the
machine stops automatically. “Auto-recovery”
and the set number is displayed.…
Error stop :Machine operation stops if an error, such as a
vision processing or pick-up error occurs.
“Error stop” is displayed in yellow.
Error pass :Machine continues to operate if an error occurs.
“Error pass” is displayed in red.
RETURN :Press to return to page 510/000.
• Function Key Menu
Chapter 3 Description of Commands
Setting Recovery
Part 3
3 – 42
RECOVERY
Page
511 000
TIMES CHANGE RETURN
Version 5.0
• Action of the Function Keys
CHANGE : Press to alternate between the 3 possible table
modes (joint, device change and changeover).
Joint mode : The two tables move jointly to
essentially form one table with 160
devices.
2A 1A : One device table is used as the
spare table.
2A 1B : Only one table operates at any one
time. Each table operates for a
separate program.
TABLE 2 : Press to set the left table as the original table.
TABLE 1 : Press to set the right table as the original table.
RETURN : Press to return to Page 510/000.
Note: Except for the use of the D RESUPPLY command on Page
554/000, device tables change only during automatic
operation. Device tables also change after the table mode has
been changed in the same manner as during automatic
operation.
• Function Key Menu
Chapter 3 Description of Commands
To page 510/000
Selecting the Table Mode
for Production
Part 3
3 – 43
TABLE MODE
Page
514 000
CHANGE TABLE 2 TABLE 1 RETURN
Version 5.0
FCP IV-3 Operation
