• Action of the Function Keys
+PAGE : Press to display the next page of input signal
statuses.
-PAGE : Press to display the previous page of input
signal statuses.
▲ : Press to move the cursor up one line.
▼ : Press to move the cursor down one line.
RETURN : Press to return to Page 521/000.
• Second Status Area
IO CHECK
Note: This page can be used for checking the status of the input
signals. Use the function keys to display the input signal to
be checked. The status of each signal changes to real time
when displayed. When the cursor is moved to the line of the
input signal to be checked, a buzzer sounds if the input signal
exists.
• Function Key Menu
Chapter 3 Description of Commands
To Page 521/000
Checking Input Signals
Part 3
3 – 48
IN
Page
521 100
+PAGE -PAGE
▲
▼
RETURN
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
+PAGE : Press to display the next page of output signal
statuses.
-PAGE : Press to display the previous page of output
signal statuses.
▲ : Press to move the cursor up one line.
▼ : Press to move the cursor down one line.
ON/OFF : The signal of the output address selected by the
cursor will be output. If the signal is being
output already then it will be cancelled.
RETURN : Press to return to Page 521/000.
• Second Status Area
IO CHECK
Note : Before exiting I/O mode, be sure to reset all the I/O settings
back to where they were before.
• Function Key Menu
Chapter 3 Description of Commands
To Page 521/000
Checking Output Signals
Part 3
3 – 49
OUT
Page
521 200
+PAGE -PAGE
▲ ▼
ON/OFF RETURN
Version 5.0
FCP IV-3 Operation
• Action of the Function Keys
TOOL : Press to select the method for checking the
vision processing system.
UTILITY : Press this for the utility function of the vision
processing software.
RETURN : Press to return to Page 520/000.
• First Status Area
VISION
• Function Key Menu
Chapter 3 Description of Commands
To Page 522/100
To Page 522/500
To Page 520/000
Checking the Vision Processing
System
Part 3
3 – 50
VISION
Page
522 000
TOOL UTILITY RETURN
Version 5.0
FCP IV-3 Operation
